Status of the circuit breaker
3.6 Status of position of withdrawable circuit breaker in the guide frame
3WA Air Circuit Breaker Communication
System Manual, 11/2021, 92310000004-02
21
3.6 Status of position of withdrawable circuit breaker in the guide
frame
The register "Circuit breaker position in the guide frame" provides a compact overview of the
positions in the guide frame, e.g. whether a fixed-mounted circuit breaker is present.
Name
Register (0x0000 HEX)
Circuit breaker position in the guide frame
0x4EC0
Description
Bit
Comment
Connected position
0
Indicates position in the guide frame.
Test position
1
Disconnected position
2
Maintenance position
3
Intermediate position
4
Circuit breaker in an intermediate posi-
tion, exact position cannot be determined.
Fixed-mounted circuit breaker
5
Fixed-mounted circuit breaker, all other
position signals (bits 0 ... 4) are therefore
invalid.
