Siemens SIMATIC IPC677D Operating Manual

BIOS Setup (SCU)
3.6 Power menu
BIOS Description
Operating Manual, 05/2016, A5E33664825-AB
31
3.6
Power menu
The reaction of the device to a power failure and after wake events is specified in the
"Power" menu. The following figure shows an example for the "Power" menu.
Parameter
Meaning
DeepSx Power Policies
1
If enabled (Enabled), the devices switches itself to idle state,
a mode with the lowest power consumption. The
DeepSx-Modes for the operating states S4 and S5 are
switched on for this purpose.
Some functions, for example Wake on LAN, that demand an
activity from parts of the device, are then no longer possible.
USB Charger
2
When enabled (Enabled), a USB port is configured so that it
remains enabled when the device is disabled and mobile
phones or tables are still loaded.
Wake on LAN
Wake on PME or LAN 2 (X2 P1)
3
Device switches on (Enabled) when a Power Management
Event or an event over LAN occurs, or does not switch on at
these events (Disabled).
Auto Wake on S5
3
Disabled The device does not switch on when it is in
the operating state S5.
By Every Day The device switches on each day when it is
in the operating state S5. Specify the time
of day.
By Day of
Month
The device switches on each month when it
is in the operating state S5. Specify the time
of day and the day.
