Siemens SIMATIC NET IE FC RJ45 Plug 4x2 CAT 6A User Manual

Frei verwendbar IE FC RJ45 Plug 4x2 CAT 6A
A5E34280610-AA, 08/20
17
Table 1-1 Pin assignment of the IE FC RJ45 4x2 CAT 6A
Pin
Color coding TIA 568 A
1
green/white
2
green
3
orange/white
6
orange
4
blue
5
blue/white
7
brown/white
8
brown
Table 1-2 Reference table
100Base-T
Color code
Color coding TIA 568 A (1)
Pin assignment RJ-45
RD+
yellow
green/white
1
RD-
orange
green
2
TD+
white
orange/white
3
TD-
blue
orange
6
blue
4
blue/white
5
brown/white
7
brown
8
(1): TIA 568 B: green/white - green: 3-4; orange/white - orange: 1 - 2
Table 1-3 Order numbers
Order number
Number per pack
6GK1901-1BB12-2AA0
1
6GK1901-1BB12-2AB0
10
6GK1901-1BB12-2AE0
50
