Siemens SIMATIC NET SCALANCE WUM766-1 User Manual

SCALANCE WxM766
Operating Instructions, 03/2022, C79000-G8976-C617-03
75
Dimension drawing
10
Note
CAx data
You can find the CAx data on the Internet at
(
https://www.automation.siemens.com/bilddb/index.aspx?lang=en)
1.
Click on the "CAx data" link in the "Direct Links" area.
The Industry Image Database page is loaded.
2.
Enter the name or article number of the product in the search filter.
You can refine your search using the "Motif type" selection list.
Note
Dimensions are specified in mm.
Front view
Width, height and dimensions for wall mounting
