Siemens SINUMERIK 808D Operating Guide

808D Page 109 Operating and Programming — Milling
Appendix
s
Unit Content
G
Functions
Group 1: Modally valid motion commands
Name Meaning
G00 Rapid traverse
G01 * Linear interpolation
G02 Circular interpolation clockwise
G03 Circular interpolation counter-clockwise
CIP Circular interpolation through intermediate point
CT Circular interpolation; tangential transition
G33 Thread cutting with constant lead
G331 Thread interpolation
G332 Thread interpolation - retraction
Group 2: Non-modally valid motion, dwell
Name Meaning
G04 Dwell time preset
G63 Tapping without synchronization
G74 Reference point approach with synchronization
G75 Fixed point approach
G147 SAR - Approach with a straight line
G148 SAR - Retract with a straight line
G247 SAR - Approach with a quadrant
G248 SAR - Retract with a quadrant
G347 SAR - Approach with a semicircle
G348 SAR - Retract with a semicircle
G
Functions
Technical
Support
Contact
Useful
Siemens
Websites
