Siemens SINUMERIK 808D Operating Guide

808D Page 77 Operating and Programming — Milling
Additional
Information
Part 2
s
Content
SEQUENCE
Unit Description
This unit describes how to perform simple tasks on the machine and
provides some additional information which may be required to operate
the machine correctly.
Part 2
Unit Content
MDA
M/H
function
Subpro-
gram
Polar
coordinates
Additive
workpiece
offsets
Coordinate
rotation
ROT AROT
Scaling
MDA
In MDA mode, you can enter and execute single
and multiple lines of NC codes.
Use MDA to move the axis to a fixed position.
Press the “MDA” key on the
Enter correct NC code to move the axis to the required position.
Program
jump
Press the “Delete file” SK on the PPU.
Calculator
Press “CYCLE START” on the MCP to execute the
MDA program.
Make sure the feedrate override on the MCP is at 0%!
Program
skip
Turn the feedrate override on the MCP gradually to the required value.
Program
example
Press the “Machine” key on the PPU.
End
