Siemens SINUMERIK 808D Operating Guide

808D Page 87 Operating and Programming — Milling
Sample
Program
s
Content
Drawing
Unit Description
This unit shows three typical program examples of frequently used milling
cycles and the corresponding machining diagrams with detailed explana-
tions.
Unit Content
Milling
program 1
Milling
program 2
Milling
program 1
Make sure all the preparations and safe-
ty measures have been performed be-
fore machining！
Tool information：
T1 Milling tool D50
T2 Milling tool D8
Actual effect
The zero point of
the workpiece is
located at the
center point of
the workpiece
Milling
program 3
Note: All the program examples in this book are only for reference. If
you want to perform actual operations, please adjust the tool offset,
coordinate moving range, workpiece plane settings, etc. according to
the actual machine conditions!
