Siemens SINUMERIK 810D Start-Up And Upgrade Guide

1 Requirements for Upgrade
Software version 06.05.26.00 (NCK 51.12.01) is a software update release. The NCK functionality
corresponds to software version 06.05.11.00 (NCK 51.07.04).
The Upgrade Instructions for software versions 06.04.15.00 and 06.05.11.00 apply to an upgrade to
version 06.05.26.00.
1.1 System software 06.05.26.00
Export versions
Order number
Designation ... on PC card
For hardware
6FC5250-6DY30-5AH0 NCU system software 2 axes NCU *.4, NCU 573.5
6FC5250-6CY30-5AH0 NCU system software 6 axes NCU *.4, NCU 573.5
6FC5250-6BY30-5AH0 NCU system software 12 axes NCU 572.3/573.2/573.3, NCU *.4,
NCU 573.5
6FC5250-6AY30-5AH0 NCU system software 31 axes NCU 572.3/573.2/573.3, NCU *.4,
NCU 573.5
6FC5450-6AY03-5AH0 CCU system software CCU 3
Standard versions (subject to export restrictions)
Order number
Designation ... on PC card
For hardware
6FC5250-6CX30-5AH0 NCU system software 6 axes NCU *.4, NCU 573.5
6FC5250-6BX30-5AH0 NCU system software 12 axes NCU 572.3/573.2/573.3, NCU *.4,
NCU 573.5
6FC5250-6AX30-5AH0 NCU system software 31 axes NCU 572.3/573.2/573.3, NCU *.4,
NCU 573.5
6FC5450-6AX03-5AH0 CCU system software CCU 3
1.2 Tools
- 6FC5250-6AY00-3AG0 SinuCom NC with SinuCom FFS
SinuCom FFS must be used to program the PC card with software version 6.4.13 and higher.
- 6FC5252-6AX21-5AG0 toolbox V 06.05.02 with basic PLC program 06.05.02 .
The basic PLC program of toolbox 6.3.3 can be used. An upgrade is not always required.
- PG/PC with Step 7 Version 5.2 and higher and optional online MPI link.
- Current documentation for SW 6 with additional function-related information
2 Back-Up
2.1 General requirements for upgrade
Before upgrading the NCK ensure that at least 50kB dynamic memory is available for each channel. This
can be checked in MD18050 INFO_FREE_MEM_DYNAMIC. If less memory is available, additional
memory must be provided by extending MD18210 USER_MEM_DYNAMIC. If this is not possible, a more
powerful CPU must be used, or unused memory must be released. The machine data, which are identified
in the list as D-RAM, are suitable for this purpose.
An additional 50KB of static memory should be available. This can be checked with MD18060
INFO_FREE_MEM_STATIC. If the available memory is insufficient, memory space can be freed by
unloading NC programs.
Set machine data 11210 UPLOAD_MD_CHANGES_ONLY = FF, 11220 INI_FILE_MODE = 1 or 2.
© Siemens AG 2004. All rights reserved SINUMERIK 810/840D Upgrade Guide
Page 3 of 8
2004-12-07
