5
6
a
rlights
and are displayed alternately, the door cannot be
m
ʑ
Additional functions
See also Programme overview apage 7
Select the desired additional functions with the Option button and then activate (or deactivate)
the chosen function with the Select button, e.g. select the Intensive function:
– For Cottons Quick iÊ programme, touch Option button,
SLess Iron indicator flashes.
– Touch Option button again until Intensive indicator flashes.
– Touch Select button. Intensive indicator flashes and related Ù
indicator comes on. It means
the function has been preselected. If you need to deselect the function immediately, touch the
Select button again.
– If no other action, the Intensive indicator stops flashing and comes on after several seconds.
Additional function is selected successfully. Setting of hRinse Plus. apage 6
iQuick
Shorten the washing time. For slightly soiled items.
SLess Iron
Special spin sequence with subsequent fluffing. Gentle final
spin – residual moisture in the laundry increased slightly.
vWater Plus
High water level to achieve better rinse result.
h
Rinse Plus
Additional rinse cycles, extended washing time. For areas
with very soft water or for further improvement of the rinsing
result. Select hRinse Plus by Option button. Then touch
Select toâactivate the function and touch Select button for
desired rinse cycles (max. 3 cycles).
Intensive
Extends the washing time for a more intensive washing
ofâheavily soiled items.
Prewash
For heavily soiled laundry. Prewash at max. 30â°C.
ʑ
Start/Reload
For starting or pausing the programme.
ʑ
Signals
ʑ
Childproof lock # Programme will not be changed by accidental operation.
To activate the childproof lock:
– After the programme starts or finish in time is activated a page 5, press and hold the Finish
in button for 5 seconds;
– Release when the s symbol lights up. If button signal is on, an acoustic signal will be heard.
When the programme ends, the Start/Reload indicator remains on to remind you to deactivate
the childproof lock.
To deactivate the childproof lock:
– Touch the Finish in button until the s symbol turns off.
– Release the button.
s symbol flashes if the programme has been changed while childproof lock is activated.
If the childproof lock is deactivated while the programme selector is in a different position
from when the childproof lock was activated, the running programme will be halted.
Set to Press °C
Temp. and
hold
1 step
clockwise
Button signals Information signals
Set volume*
Set volume*1 step
clockwise
Set to
1. Start signal mode
2. Set volume for ...
Release
#
*If required, set repeatedly
1 step
clockwise
direct
a
a
ʋ
ʋ
ʋ
ʋ
ʋ
ʋ
ʋ
ʋ
ʋ
ʋ
ʋ
ʋ
ʋ
ʋ
ʋ
ʋ
ʋ
ʺ
a
~
ʋ
ʋ
ʋ
ʑ
Display symbols
ʑ
Display information
Alternating display of Load
information, maximum load
recommendation in kg and remain
time or finish in time display.
* âExample of display, may vary
depending on selections.
ʑ
Option buttons
You can change the spin speed and temperature beforehand and while the selected programme
is running. The effects depending on the progress of the programme.
°C Temp.
You can change the indicated washing temperature. The maximum washing temperature which
can be selected depends on the programme that has been chosen. apage 7
Spin
You can change the indicated spin speed. The maximum spin speed which can be selected
depends on the chosen programme. If is selected, the load is held in the rinsing water.
Load
You can change loading level from to , or . The remaining time will be
adapted accordingly.
: Remaining time defined according to the weight of loading automatically by machine.
: For small load quantities, select it to reduce programme duration.
: Select this function for washing half of the recommended max. load.
: Select this function for washing of the recommended max. load.
Finish in
When you select a programme, the respective programme duration is displayed. You can delay
the start of the programme before it begins. The finish-in time indicates when the programme will
be finished. It can be set in hour increments up to a maximum of 24h. Press and hold the
Finish in button until the required number of hours is shown (h=hour). Select Start/Reload.
Prewash: On if prewash process is running.
tWashing: On if wash process is running.
mRinse: On if rinse process is running.
Spin: On if spin process is active.
xTap:Flashing if tap not open or no water supply.
kOverdosage: Foam detected. Maybe too much detergent.
rüDoor:On if door can be opened.
sChildproof lock: On if childproof lock is activated.
Flashing if there is misoperation.
Activate/deactivate childproof lock. apage 6
Load, e.g. *: load of laundry, detect by machine or defined by
user a page 5
Kg, e.g. *:max. recommanded for selected programme.
apage 7, Programme overview
Time, e.g. *: programme remaining time, or
*:Finish-in time defined by user a page 5
: On if programme is in pause.
:On if door can be opened when programe was paused.
: End of programme, or
end of programme with the setting
*:
set volume of signals apage 6
set additional rinse cycles apage 6
*: Fault displays apage 10
~
Display information, Options, Functions Options, Functions
#
a
a
a
iÊ
Ê
n
düÉ
Ú
m
6
-
iÊ
:
Ê:
n:
:
-:
:düÉ
6
Ú:
:
:
:
:
:
m
Êiü
