ENGINE
Make ................................................................Tecumseh
Cylinders........................................................................1
Cycles.............................................................................4
Crankshaft .......................................................Horizontal
8 HP
- Model No. .....................................See engine I.D. plate
- Bore & Stroke ..............................3-1/8 in. x 2-17/32 in.
(79.38 mm x 64.31 mm)
- Displacement.............................................19.41 cu. in.
(318.27 cc)
9 HP
- Model No. .....................................See engine I.D. plate
- Bore & Stroke ..............................3-1/8 in. x 2-17/32 in.
(79.38 mm x 64.31 mm)
- Displacement.............................................19.41 cu. in.
(318.27 cc)
10 HP
- Model No. .....................................See engine I.D. plate
- Bore & Stroke ............................3-3/16 in. x 2-17/32 in.
(89.96 mm x 64.31 mm)
- Displacement.............................................20.20 cu. in.
(331.06 cc)
Ignition ...............................................................Magneto
Governor........................................................Mechanical
Choke ...................................................................Manual
Lubrication ...............................................Splash system
Oil Capacity ......................................See engine manual
Fuel Capacity....................................See engine manual
TRACTION DRIVE
Type...........................Friction drive transmission w/chain
gear drive and speed selection
Speeds...............................Five forward and two reverse
Axle ....................Solid w/klik-pin lock for two-wheel drive
Tire Inflation ..........................................20 psi (137 kPa)
AUGER HOUSING
Construction..............................Welded steel stampings
Effective Width
- Model 8-60cm/24 .....................................24 in. (60 cm)
- Model 8-70cm/28 .....................................28 in. (70 cm)
- Model 9-70cm/28 .....................................28 in. (70 cm)
- Model 10-80cm/32 ...................................32 in. (80 cm)
Auger Opening Height...........................19 in. (47.5 cm)
Spout Rotation ............................................210 degrees
Scraper Bar.................High Carbon, wear resistant steel
Skid Shoes........................Adjustable, heat-treated steel
AUGER
Construction.............................Ribbon flite welded steel
Bearings...................................................Self-lubricating
IMPELLER
Construction..............................................4 steel blades
Bearings ..............Pre-lubricated and sealed ball bearing
Diameter.....................................................12 in. (30 cm)
AUGER & IMPELLER DRIVE
Type....................Cushion V-belt and worm gear housing
OVERALL DIMENSIONS & WEIGHT
Model 8-60cm/24
- Length.........................................56-7/8 in. (142.18 cm)
- Width........................................................26 in. (65 cm)
- Height............................................37-3/8 in. (93.44 cm)
- Weight .................................................240 lbs. (109 kg)
Model 8-70cm/28
- Length.........................................56-7/8 in. (142.18 cm)
- Width........................................................30 in. (75 cm)
- Height............................................37-3/8 in. (93.44 cm)
- Weight .................................................255 lbs. (115 kg)
Model 9-70cm/28
- Length.........................................56-7/8 in. (142.18 cm)
- Width........................................................30 in. (75 cm)
- Height............................................37-3/8 in. (93.44 cm)
- Weight .................................................255 lbs. (115 kg)
Model 10-80cm/32
- Length.........................................56-7/8 in. (142.18 cm)
- Width........................................................34 in. (85 cm)
- Height............................................37-3/8 in. (93.44 cm)
- Weight .................................................265 lbs. (120 kg)
Specifications
SPECIFICATIONS ARE CORRECT AT TIME OF
PRINTING AND ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
