Simplicity Baron XL User Manual

40" Mower Deck - Housing, Arbors & Blade
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
Torque screws to
50-70 ft/lbs
(68-95 Nm.)
Torque screws to
50-70 ft/lbs
(68-95 Nm.)
RH
LH
Torque to 45-55 ft/lbs
(61-75 Nm.)
27
13
26
33
28
29
30
1
23
32
30
29
28
3
27
13
26
20
25
24
22
13
12
1317
18
16
21
31
13
2
4
10
11
8
9
7
114
15
25
6
5
5
6
19
986817
The above parts group applies to the following Mfg. Nos.:
2005
52
© Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694790 - 40" Mower
1694796 - 40" Mower
TP 400-4198-00-BR-SM

Simplicity Baron XL Specifications
