Simplicity Broadmoor series User Manual

Adjusting Mower Cutting Height
The height-of-cut switch (A, Figure 5) adjusts the mower
cutting height. Press the switch UP to raise the mower
cutting height and DOWN to lower the mower cutting
height. The cutting height is infinitely adjustable between
1.0” and 4.0” (2,5 and 10,2 cm).
Figure 5. Mower Cutting Height Switch
A
Attaching a Trailer
The maximum horizontal drawbar force allowed is 444
Newton. The maximum vertical drawbar force is 222
Newton. This equates to a 396 lbs (180 kg) trailer on a
10 degree hill. Secure the trailer with an appropriately
sized clevis pin (A, Figure 6) and clip (B).
(180kg)
396 Lbs.
10˚
3'4"
(1m)
20' (6m)
Figure 6. Trailer Weight Recommendations
A
B
OPERATION
17
Not for
Reproduction
