26
ENGINE
14 HP Briggs & Stratton
Make: Briggs & Stratton - 4 cycle air cooled
Model & Type: See engine l.D. plate
Horsepower: 14 HP @ 3600 rpm (Eng. Mfg’s. Rating)
Cylinder: 1 horizontal
Bore & Stroke: 3.44 x 3.06 inches (87.3 x 77.7 mm)
Displacement: 28.4 cu. in. (465 cc)
Construction: Overhead valve, cast iron sleeves, aluminum
crankcase
Electrical: Hydro - 12 volt 9 amp. alternator regulated bat-
tery, 12 volt, 340 cranking amps, 41 minute
reserve capacity.
Gear - unregulated 3 amp. DC charging circuit.
Governor: Mechanical full throttle -
no load setting @ 3400 ± 100 rpm;
idle speed @ 1750 ± 200 rpm
Oil Capacity: 4.0 pints w/filter (1.9 L)
Ignition: Magnetron electronic
Charging: Unregulated 3-amp DC charging circuit
Air Cleaner: Ducted paper cartridge and foam pre-cleaner
Fuel Tank: High density polyurethane construction; 2 gal-
lons (7.57 liters) of “regular” grade leaded or
nonleaded gasoline.
Muffler Large, low back pressure, remote canister type
Starter: 12 volt electric gear drive
15.5 HP Briggs & Stratton
Make: Briggs & Stratton - 4 cycle air-cooled
Model & Type: Daimond I/C
Horsepower: 15.5 HP
Cylinder: Dura Bore
Bore & Stroke: 3.44in.(87.3)mm
Displacement: 28.4cu.in.(465cc)
Construction: Overhead valve, Dura Bore Sleeves,
Aluminum Crankcase.
Electrical: Hydro - 12 volt 9 amp, alternator
regulated battery, 12 volt, 340 cranking
amps, 41 minute reserve capacity.
Governor: Mechanical
Oil Capacity: 3 Pints w/Filter (1.4 L)
Ignition: Magnetron Electronic
Charging: Unregulated 3 amp DC charging circuit
Air Cleaner: Tri-Clean
Fuel Tank: High Density polyurethane construction;
2 gallons (7.57 liters) of “regular” grade
leaded or non-leaded gasoline.
Muffler: Square Lo-Tone
Starter: Electric
16 HP Briggs & Stratton
Make: Briggs & Stratton - 4 cycle air cooled
Model & Type: Vanguard
Horsepower: 16 HP
Cylinder: 1
Bore & Stroke: 3.44 in./87.3 MM (3.06 in./77.7 MM)
Displacement: 28.4 cu.in.(465cc)
Construction: Overhead valve, Cast Iron Sleeves,
Aluminum Crankcase.
Electrical: Hydro - 12 volt 9 amp, alternator regulated
battery, 12 volt, 340 cranking amps, 41
minute reserve capacity.
Governor: Mechanical
Oil Capacity: 3.5 Pints w/Filter (1.7 L)
Ignition: Magnetron Electronic
Charging: Unregulated 3 amp DC charging circuit
Air Cleaner: Dual Element
Fuel Tank: High Density polyurethane construction;
2 gallons (7.57 liters) of “regular” grade
leaded or non-leaded gasoline.
Muffler: Super LoTone
Starter: 12 volt electric gear drive
TRANSMISSION - GEAR
Type: Spur gear
Material: Shaft hardened
Lubrication: Oil
Ground speeds 1st gear : 1.0 mph (1.6 km/h)
@ 3400 rpm: 2nd gear : 2.0 mph (3.2 km/h)
3rd gear : 2.9 mph (4.7 km/h)
4th gear : 3.9 mph (6.3 km/h)
5th gear : 4.3 mph (6.9 km/h)
Reverse : 1.3 mph (2.1 km/h)
TRANSMISSION - HYDRO
Type: Hydrostatic
Pump: Variable displacement axial piston
Motor: Fixed displacement axial piston
Control: Foot pedal, free-wheeling lever for manual trac-
tor movement
Ground speeds Forward: 0-4.7 mph (7.5 km/h)
@ 3400 rpm: Reverse: 0-2.6 mph (4.1 km/h)
DIMENSIONS
Height : 41.25 in. (105 cm) — at steering wheel
Width: 35 in. (89 cm)
Length: 67.75 in. (172.1 cm)
Wheel Base: 45.5 in. (116 cm)
Weight: 90 lbs. (40.1 kg) — with Mower
Cutting Width: 38 in. (9.65 cm)
Cutting Height: Variable between 1" - 3.9"
(215 - 9.9 cm)
Front Tires: 15 x 6.00 x 6 pneumatic
12-15 psi (82-103 kPa)
Rear Tires: 18 x 8.50 x 8 pneumatic,
10-12 psi (56-82 kPa)
Turning radius: Inside rear tire 14" (35.6 cm)
Specifications
NOTE: Specifications are correct at time of printing and are subject to change without notice.
