43
THIS IS A 15 DEGREE SLOPE
INSTRUCTIONS
1. Fold this page along the
dotted line indicated above.
2. Align the left edge of this guide
with a vertical tree, a power line
pole, a fence post, or any vertical
structure.
3. Compare the angle of the fold
with the angle of the hill.
SLOPE INDENTIFICATION GUIDE
ALIGN THIS EDGE WITH A VERTICAL SURFACE
(TREE, POLE, FENCE POST, BUILDING, ETC)
COMPARE THE ANGLE
OF THE FOLD TO THE
ANGLE OF THE SLOPE
2
3
THIS IS A 10 DEGREE SLOPE
FOLD ALONG APPROPRIATE DOTTED LINE
1
Not for
Reproduction
