Singer 20U-125C User Manual

25
3.24
Figure 34
Buttonhole Foot ‘1’, Needle plate ‘2’
(Zigzag stitch) and Feed Dog ‘3’ are
used for buttonhole stitching.
(Figure
35)
Fittings for
Buttonhole
Stitching
410192 541937-452 543979
606688(20U-105/105C
)
606502(20U-125/125C)
606652(20U-105/105C)
606402(20U-125/125C)
3.25
Figure 3
5
Figure 3
6
The hem foot ‘1’, needle plate ‘2’
(Straight stitch) and feed dog ‘3’ can
turn and stitch a narrow hem in a
single operation as the following
condition. (Figure 36 and 37)
1. Needle position selector:
Center position
2. Stitch width regulate:
Straight stitch position.
Fittings for
Hem Sewing
1
1
606692(20U-105/105C
/125/125C)
2
2
3
3
Zigzag Sewing Machine
|
Instruction Manual and Parts List
