Singer 5532 - EN Changing the Bulb

1
2
55
A
B
Changing the Bulb
EN
Disconnect the machine from the power supply by removing
the plug from the main socket!
Replace bulb with same type rated 15 watts (110-120V area
/ 220-240V area).
- Loosen screw (A) as illustrated. (1)
- Remove the face plate (B).
- Unscrew the bulb and install a new one (C). (2)
- Replace the face plate and tighten screw.
Should there be any problem, consult your SINGER retailer.
®
C
