Singer S14-78 User Manual

Deactivate the Upper Cutter
R
2
4
3
• Turn the hand wheel toward you until the upper cutter is in
its lowest position.
• Turn off the upper cutter by switching the upper cutter
switch to non-cutting position (A).
Reactivate the Upper Cutter
• Turn on the upper cutter by switching the upper cutter
switch to cutting position (B).
Note: Always have the upper cutter in the cutting position when
sewing, because this machine must trim off any excess fabric to
form the stitch over the fabric edge. An exception to this is when
sewing decorative flatlock seams. Then the upper cutter needs to
be turned off.
Attach the 2–thread Overlock
Converter
A
B
C
D
2-thread overlock stitches are sewn using one needle thread
and the lower looper thread. Before sewing, the two-thread
converter must be attached to the upper looper, so the machine
will sew with only two threads.
1. Open the front cover.
2. Bring the upper looper to its lowest position by turning the
hand wheel toward you.
3. Insert the tip of the converter (A) into the hole of the upper
looper (B).
4. Push the converter (C) down into the slot of the upper
looper.
Remove the 2-thread Overlock Converter
Remove the converter by tilting it toward you (D).
6 – About Your Machine
English

Singer S14-78 Specifications

General

Maximum Sewing Speed	1300 stitches per minute
Differential Feed	Yes
Adjustable Stitch Length	Yes
Adjustable Stitch Width	Yes
Free Arm	Yes
Color-Coded Threading	Yes
Stitch Formation	Overlock
Needle Threader	Yes
Presser Feet	Standard Overlock Foot
Weight	6.5 kg
Warranty	2 years
Stitch Options	4-Thread Overlock, 3-Thread Overlock, Rolled Hem
Included Accessories	Needles, screwdriver, tweezers, spreader
Dimensions	30 x 27 x 29 cm
