Singer SE017 User Manual

Parts of the machine
1. Presser foot pressure adjustment
2. Leftneedlethreadtensiondial(blue)
3. Rightneedlethreadtensiondial(green)
4. Upperlooperthreadtensiondial(purple)
5. Lowerlooperthreadtensiondial(yellow)
6. Handle
7. Presser foot lifter
8. Stitchplate
9. Flat bed extension
10.Frontcover
11.Dierentialfeedadjustinglever
12. Power & light switch
13. Hand wheel
14.Stitchlengthdial
15.Spoolstand
16. Cone holder
17.Spoolpin
18. Telescopic thread stand
19. Presser foot
20.Movableuppercutter
21.Stationarylowercutter
22. Lower looper
23. Upper looper
24.Stitchngerlever
25.Seamwidth/cuttingwidthadjustmentknob
26.LED-light,(availableoncertainmodels)
5
24
21
20
26
25
23
22
27
1
2 3 4 5
6
7
8
9
10
11
12
13
14
15
16
17
18
23
20
19
25
24
22
21
26

Singer SE017 Specifications

General

Brand	Singer
Model	SE017
Category	Sewing Machine
Language	English
