74
2
1
(1)
(2)
3
4
5
(A)
(B)
(3)
(4)
3. CARING FOR YOUR MACHINE
CLEANING HOOK AREA AND FEED
DOGS
CAUTION
Always disconnect the machine from power supply
by removing the plug from the wall-outlet.
To ensure the best possible operation of your machine, it is
necessary to keep the essential parts clean at all times.
1. Raise the needle to its highest position.
2. Remove the needle plate (1).
3. Remove the bobbin case (2).
4. Clean the feed dogs and hook area with the lint brush.
Put
one drop of sewing machine oil on the hook race as
indicated by the arrows. (A, B)
5. Replace the bobbin case with the projection (3) positioned
against the spring (4). Replace the needle plate.
NOTE: Singer Brand Sewing Machine Oil is suggested.
DO NOT use “all purpose” oil as it is not suited for sewing
machine lubrication.
