Sloan SF Series User Manual

3
X
X
X
X
A
Install Mounting
Stud.
B
Install Flex Hose.
X
X
X
X
A
Install Flex Hose.
1A - SF-2100/2150 & SF-2400/2450
SERIES: INSTALL FLEX HOSE
AND MOUNTING STUD
1B - SF-2200/2250 & SF-2300/2350
SERIES: INSTALL FLEX HOSE
2A - SF-2100/2150, SF-2200/2250, & SF-2400/2450 SERIES: INSTALL SPOUT, TRIM
PLATE AND SPACER
X
X
X
X
Pedestal
Spout
Spacer
Trim Plate
X
X
X
X
Spacer
Trim Plate
Pedestal
Spout
A
Apply a bead of plumbers putty around the outside of the
Faucet underbody.
Pedestal
Spout
Spacer
Trim Plate
2B - SF-2300/2350 SERIES: INSTALL SPOUT
