FLEXIBLE ASSEMBLY SYSTEM FAS200
User Manual for FAS200 - 10 -
The system comprises a flexible automation cell which carries out an assembly
process involving a number of predetermined parts with a total of 24 different
possibilities.
Figure 5: Turning mechanism Figure 6: Turning mechanism
components
Parts are transported between the different modules by an automated linear
transfer with corresponding stoppers and precision lifters-positioners. Parts are
mounted on pallets.
Figure 7: Linear transfer for 4 modules. Figure 8: Linear transfer for 8 modules.
