13
Ignition Switch
The ignition switch starts and stops the engine; it has three
positions:
OFF Stops the engine and shuts off the
electrical system.
RUN Allows the engine to run and powers the
electrical system.
START Cranks the engine for starting.
NOTE: Never leave the ignition switch in the RUN position with
the engine stopped–this drains the battery.
PTO Switch
The PTO (Power Take-Off) switch engages and disengages the
mower blade clutch. To engage the PTO, pull UP on the switch.
Push DOWN to disengage. Note that the operator must be
seated firmly in the rider seat for the PTO to function.
Transmission Release Levers
The transmission release levers deactivate the transmissions so
that the unit can be pushed by hand. See PUSHING THE UNIT
BY HAND for operational information.
Seat Adjustment Lever
The seat can be adjusted forward and backward. See SEAT
ADJUSTMENTS for adjustment information.
Fuel Tank Cap
To remove the cap, turn counterclockwise.
Mower Cutting Height Adjustment Switch
The mower cutting height is adjustable from 1-1/2” to 3-3/4”.
See CUTTING HEIGHT ADJUSTMENT for adjustment
information.
Parking Brake
Moving the parking brake lever forward and to the right
engages the parking brake. Moving the lever to the left and
back disengages the brake.
Hour Meter
The hour meter measures the number of hours the key has
been in the RUN position.
Note: The hour meter will register the passage of time when the
engine is running. The hour meter has a self contained power
source so the total hours are always visible.
IMPORTANT
The figures and illustrations in this manual are provided
for reference only and may differ from your specific
model. Contact your dealer if you have questions.
Features and Controls
