Snapper XD Series User Manual

PARTS LIST
22
ITEM NO. PART NO. DESCRIPTION QTY
53 ----- BEARING, BALL 1
54 ----- SCABBARD 3
55 ----- RING, HOLE WITH 1
56 ----- CUSHIONING 2
57 ----- PIN, POSITIONING 2
58 ----- SCREW 2
59 ----- INSERT 1
60 ----- SPRING, BATTERY POP-UP PRESSURE 2
61 ----- PCB 1
8 770214 GUARD 1
9 770215 KIT, GEAR CASE 1
83 ----- SCREW 6
84 ----- GASKET, SPRING 6
85 ----- GASKET, GEAR BOX 1
86 ----- BEARING, BALL 1
87 ----- COVER, GEAR BOX 1
88 ----- PAD, WATERPROOF 1
10 770216 GUARD, TIP 1
11A 770217 KIT, BLADE ASSEMBLY, NA 1
89 ----- SLOT, LOCATING 1
90 ----- SCREW 2
91 ----- GASKET, SPRING 2
92 ----- BLADE 1
12A 770218 KIT, HANDLE & GUARD ASSEMBLY, NA 1
99 ----- SCREW 3
100 ----- GUARD, HAND 1
101 ----- SCREW 8
102 ----- COVER, AUXILIARY HANDLE (DOWN) 1
103 ----- COVER, AUXILIARY HANDLE (UP) 1
104 ----- CUSHIONING 2 2
105 ----- CUSHIONING 1 2
106 ----- SCREW 2
107 ----- GASKET 5 2
108 ----- GASKET, SPRING 2
13 770219 KIT, CONNECTING ROD ASSEMBLY 1
129 ----- GEAR 1
130 ----- GASKETS, COPPER 1
131 ----- ASSY, CAM BLOCK 1
132 ----- GASKETS, COPPER 1
133 ----- RING, LINK 1
134 ----- RING, COMPRESSION 1
135 ----- CIRCLIP 1
