EN
Control Box 3S io
2 Copyright © 2011 Somfy SAS. All rights reserved
USE AND OPERATION
Normal operation
Using Keygo io type remote controls
Using Keytis io type remote controls
PRODUCT DESCRIPTION
The control box is designed to control one or two Somfy 24V motors for opening and closing gates.
5
6
2 s
< 0.5 s
Complete opening (Fig. 5)
Pressing and holding the remote control button will cause the gate to open fully.
Pedestrian opening (Fig. 6)
Briey pressing the remote control button will cause the gate to open in pedestrian mode.
7
Closing (Fig. 7)
1
Complete opening (Fig. 1)
Press the programmed button to open the gate fully.
3
2
Closing (Fig. 3)
Pedestrian opening (Fig. 2)
Press the programmed button to open the gate in pedestrian mode.
Stop (Fig. 4)
4
STOP
