Sonoff S-MATE User Manual

3. Wiring instruction
N
L in
LOut
N
S S1 S2 S3
L3
L2
L
L1
LOut
100-240V AC
N N
L
L1
L2
L3
N
L in
LOut
N
LOut
N N
N
L in
LOut
N
LOut
N N
The wiring instruction of connecting the S-MATE with three MINIR3:
S
S1
S2
S3
The dip switch is factory set to the right. Please toggle the dip switch to the left if connection
a pulse switch to the device.
S S1 S2 S3
L3
L2
L
L1
100-240V AC
L
L1
S
S1
N
L in
LOut
N
LOut
N N
The wiring instruction of connecting the S-MATE with one MINIR3:
翘板开关
Make sure the neutral wire and live wire connection is correct.
Dip Switch
Rocker Switch
There are L/L1/L2/L3 on the S-MATE which can be used as terminal connectors, but you have
options to directly connect the L wire of MINIR3 to the L wire in the switching box without
going through the S-MATE.

Sonoff S-MATE Specifications

General

Brand	Sonoff
Model	S-MATE
Category	Switch
Language	English
