11-GB
Specifications
Battery Charger BC-CSQ2
Input rating AC 100 - 240 V, 50/60 Hz
7 W, 12 VA - 15 VA
Output rating DC 1.2 V, 460 mA × 4 / 920 mA × 2
Operating temperature 0°C to +40°C (32°F to 104°F)
Dimensions Approx. 65 × 32 × 106 mm (w/h/d)
(2
5
/
8
× 1
5
/
16
× 4
1
/
4
inches)
Mass Approx. 120 g (4 oz)
Applicable batteries Sony Nickel-Metal Hydride rechargeable
batteries
HR11/45, HR03 (size AAA), NH-AAA
HR15/51, HR6 (size AA), NH-AA
Rechargeable Battery NH-AAA-DI
Nominal voltage 1.2 V
Capacity 750 mAh (typ.)
Operating temperature 0°C to +40°C (32°F to 104°F)
Design and specifications are subject to change without notice.
Remove the
batteries, and
then re-insert
the same
batteries into
the charger.
If the lamp blinks
again, or doesn’t
light.
Insert a different set
of batteries.
If the lamp blinks
again, or doesn’t light.
There may be a
problem with the
charger.
Contact your
nearest Sony
dealer when
you think
there is a
problem
with the
charger
itself.
If the lamp doesn’t
blink after it comes
on.
If, when the
charging time has
been exceeded, the
lamp goes out, there
is no problem.
If the lamp doesn’t
blink after it comes on.
If the lamp goes out
when the charging
time is exceeded, there
is a problem with the
first set of batteries, or
they have exceeded
their normal useable
battery life.
Troubleshooting procedures
