Additional Information
Supported Audio
Formats
Audio formats supported by this system are
as follows.
a: Supported format.
–: Unsupported format.
* Decoded as DTS core.
For LPCM 2ch format, the supported sampling
frequency of the digital signal is up to 48 kHz
when using the “TV” function.
Specifications
Amplifier Section
U.S.A. model only:
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
(FTC)
Front L + Front R:
With 3 ohms loads, both channels driven,
from 180 Hz – 20,000 Hz; rated 50 watts
per channel minimum RMS power, with
no more than 1% total harmonic
distortion from 250 milliwatts to rated
output.
Other models:
POWER OUTPUT (rated)
Front L/Front R:
75 W + 75 W (at 3 ohms, 1 kHz,
1% THD)
POWER OUTPUT (reference)
Front L/Front R/Surround L/Surround R:
125 W (per channel at 3 ohms, 1 kHz)
Center:
250 W (at 6 ohms, 1 kHz)
Subwoofer:
250 W (at 6 ohms, 80 Hz)
Inputs (Analog)
AUDIO IN
Sensitivity: 1 V/400 mV
Inputs (Digital)
TV (Audio Return Channel/OPTICAL)
Supported formats: LPCM 2CH (up to
48 kHz), Dolby Digital, DTS
HDMI Section
Connector
Type A (19pin)
BD/DVD/CD System
Signal format system
NTSC
USB Section
(USB) port:
Type A (For connecting USB memory,
memory card reader, digital still camera,
and digital video camera)
Format
Function
“BD/DVD” “TV”
(DIGITAL IN)
LPCM 2ch
aa
LPCM 5.1ch,
LPCM 7.1ch
a –
Dolby Digital
aa
Dolby TrueHD,
Dolby Digital
Plus
a –
DTS
aa
DTS-ES
Discrete 6.1,
DTS-ES Matrix
6.1
a* a*
DTS96/24
aa*
DTS-HD High
Resolution
Audio
a –
DTS-HD Master
Audio
a –
Note
