Sony Cyber-Shot DSC-HX90 User Manual

GB
9
DSC-HX90V/HX90/HX80
A ON/OFF (Power) button
B Shutter button
C Mode dial
(Intelligent Auto)/
(Superior Auto)/
(Program Auto)/
(Aperture Priority)/
(Shutter Priority)/
(Manual Exposure)/
(Memory recall)/
(Movie)/ (iSweep
Panorama)/ (Scene
Selection)
D For shooting: W/T (zoom) lever
For viewing: (Index) lever/
Playback zoom lever
E Self-timer lamp/AF illuminator
F GPS receiver (built-in, DSC-
HX90V only)
G Flash
• Do not cover the flash with your
finger.
• When using the flash, slide the
(Flash pop-up) switch. If not
using the flash, press it down
manually.
H Diopter-adjustment lever
I Viewfinder
• When using the viewfinder, slide
down the viewfinder pop-up
switch (1), then pull the
eyepiece out from the viewfinder
until it clicks (2).
• When you look into the
viewfinder, the viewfinder mode
is activated, and when you take
your face away from the
viewfinder, the viewing mode
returns to the monitor mode.
J Viewfinder pop-up switch
K (N Mark)
• Touch the mark when you
connect the camera to a
smartphone equipped with the
NFC function.
• NFC (Near Field
Communication) is an
international standard of the
short-range wireless
communication technology.
L Control ring (DSC-HX90V/
HX90 only)
M Lens
Identifying parts

Sony Cyber-Shot DSC-HX90 Specifications

General

Effective Pixels	18.2 MP
Optical Zoom	30x
Lens	Zeiss Vario-Sonnar T* lens
LCD Resolution	921, 600 dots
Connectivity	Wi-Fi, NFC
Shutter Speed	30 - 1/2000 sec
Weight	245 g (Including battery and memory card)
Built-in Flash	Yes
Sensor Type	Exmor R CMOS
ISO Sensitivity	ISO 80-3200
Display	3.0-inch TFT LCD
Video Recording	Full HD 1080p
Viewfinder	0.2-type electronic viewfinder
Battery	NP-BX1
Battery Life	Approx. 390 shots
Dimensions	102.0mm x 58.1mm x 35.4 mm
