A ON/OFF (Power) button
B Shutter button
C W/T (Zoom) lever
D Flash
E Power/Charge lamp
F (Playback) button
G Microphone
H Self-timer lamp/Smile Shutter
lamp/AF illuminator
I Lens
J Screen/Touch panel
K HDMI mini jack
L Hook for wrist strap
M (TransferJet™) mark
N Speaker
O Tripod receptacle
• Use a tripod with a screw less
than 5.5 mm (7/32 inches) long.
Otherwise, you cannot firmly
secure the camera, and damage to
the camera may occur.
P Micro USB connector
Q Memory card slot
R Battery/memory card cover
S Battery insertion slot
T Access lamp
U Battery eject lever
Identifying parts
