DCR-HC36/HC36E_L2
SPECIFICATIONS
These specifications are extracted from
instruction manual of DCR-HC36/HC46/HC96.
System
Video recording system
2 rotary heads, Helical scanning system
Still image recording system
Exif Ver. 2.2*
1
Audio recording system
Rotary heads, PCM system
Quantization: 12 bits (Fs 32 kHz, stereo
1, stereo 2), 16 bits (Fs 48 kHz, stereo)
Video signal
NTSC color, EIA stan dards
Usable cassette
Mini DV cassette with the mark
printed
Tape speed
SP: Approx. 18.81 mm/s
LP: Approx. 12.56 mm/s
Recording/playback time
SP: 60 min (using a DVM60 cassette)
LP: 90 min (using a DVM60 cassette)
Fast forward/rewind time
Approx. 2 min 40 s (using a DVM60
cassette and rechargeable battery pack)
Approx. 1 min 45 s (using a DVM60
cassette and AC Adaptor)
Viewfinder
Electric viewfinder (color)
Image device
DCR-HC36:
3.0 mm (1/6 type) CCD (Charge
Coupled Device)
Gross: Approx. 680 000 pixels
Effective (still): 340 000 pixels
Effective (movie): 340 000 pixels
Lens
DCR-HC36:
Carl Zeiss Vario-Tessar
20 × (Optical), 800 × (Digital)
Focal length
DCR-HC36:
f=2.3 ~ 46 mm (3/32 ~ 1 13/16 in.)
When converted to a 35 mm still
camera
In CAMERA-TAPE:
44 ~ 880 mm (1 3/4 ~ 34 1/32 in.)
In CAMERA-MEMORY:
44 ~ 880 mm (1 3/4 ~ 34 1/32 in.)
F1.8 ~ 3.1
Filter diameter: 25 mm (1 in.)
Color temperature
[AUTO], [ONE PUSH], [INDOOR]
(3 200 K), [OUTDOOR] (5 800 K)
Minimum illumination
DCR-HC36/HC96:
5 lx (lux) (F 1.8)
0 lx (lux) (during NightShot plus
(DCR-HC36)/NightShot (DCR-HC96)
function)*
3
*
1
“Exi
f” is a file format for still images,
established by the JEITA (Japan
Electronics and Information Technology
Industries Association). Files in this
format can have additional information
such as your camcorder’s setting
inform
ation at the time of recording.
*
2
In 16:9 mode, the focal length figures
are actual figures resulting from wide
angle pixel read-out.
*
3
Objects unable to be seen due to the dark
can be shot with infrared lighting.
Input/Output connectors
Audio/Video output
DCR-HC36/HC46:
10-pi n connector
Video signal: 1 Vp-p, 75 Ω (ohms),
unbalanced
Luminance signal: 1 Vp-p, 75Ω
(ohms), unbal anced
Chrominance signal: 0.286 Vp-p, 75Ω
(ohms), unbal anced
Audio signal: 327 mV (at load
impedance 47 kΩ (kilohms)), Output
impedance with less than 2.2 kΩ
(kilohms)
USB jack (DCR-HC36)
mini-B
DV input/output (DCR-HC36)
i.LINK Interface (IEEE1394, 4-pin
connector S100)
LCD screen
DCR-HC36:
6.2 cm (2.5 type)
Total dot number
123 200 (560 × 220)
General
Power requirements
DC 7.2 V (battery pack)
DC 8.4 V (AC Adaptor)
Average power consumption
DCR-HC36:
During camera recording using the
viewfinder 1.9 W
During camera recording using the
LCD 2.3 W
Operating temperature
0 °C to 40 °C (32 °F to 10 4 °F)
Storage temperature
-20 °C to + 60 °C (-4 °F to + 140 °F)
Dimensions (approx.)
DCR-HC36/HC46:
65 × 79 × 113 mm
(2 5/8 × 3 1/8 × 4 1/2 in.) (w/h/d)
Mass (approx.)
DCR-HC36:
370 g (13 oz) main unit only,
430 g (15 oz) including the NP-FP30
rechargeable battery pack and DVM60
cassette
AC Adaptor (1)
Power cord (1)
Wireless Remote Commander (1)
A/V connecting cable (1)
USB cable (1)
Lens cap (1) (DCR-HC36/HC46)
Rechargeable battery pack (1)
NP-FP30 (DCR-HC36)
CD-ROM “Picture Package Ver.1.5.1” (1)
Operating Guide (1)
See page 5-21.
Supplied accessories
AC
Adaptor AC-L25A/L25B
Power requirements
AC 100 - 240 V, 50/60 Hz
Current consumption
0.35 - 0.18 A
Power consumption
18 W
Output voltage
DC 8.4 V*
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to + 60 °C (-4 °F to + 140 °F)
Dimensions (approx.)
56 × 31 × 100 mm (2 1/4 × 11/4 × 4 in.)
(w/h/d) excluding the projecting parts
Mass (approx.)
190 g (6.7 oz) excluding the power cord
*
See the label on the AC Adaptor for
other specifications.
Rechargeable battery pack
NP-FP30 (DCR-HC36)
Maximum output voltage
DC 8.4 V
Output voltage
DC 7.2 V
Capacity
3.6 Wh (500 mAh)
Dimensions (approx.)
31.8 × 18.5 × 45.0 mm
(1 5/16 × 3/4 × 113/16 i n) (w/h/d)
Mass (approx.)
40 g (1.5 oz)
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Type
Lithium ion
Design and specifications are subject to change
without notice.
