8-GB
Parts identification
See pages in ( ) for more details.
To insert the floppy disk
Insert the floppy disk until it clicks.
Before inserting, check that the
write protect tab set to the
recordable position.
To remove the floppy disk
While pressing PUSH, slide DISK EJECT in the direction of the arrow.
DISK EJECT lever
PUSH button
Shutter button
(16)
Self-timer lamp
The lamp keeps on
blinking until
recording starts after
the shutter button is
depressed.
Flash emitter (10)
Lens
Tripod receptacle
Make sure that the length of the
tripod screw is less than
7/32 inch (6.5 mm).
Slot for AC
power adaptor code
Photocell window
for flash
Do not block when
recording.
Lens cap
