Location and Function of Parts
1 R (right) indication
2 Right (R) unit
3 Multi function button
Controls various call functions.
4 POWER button
5 Microphone
6 RESET button
Push this button when this unit
does not operate properly.
Pairing information is not
deleted by this operation.
7 VOL (volume) +*⁄–
buttons
8 Indicator (blue)
Indicates the communication
status of the unit.
9 Indicator (red)
Indicates the power status of
the unit.
0 Jog switch
Controls various functions
when listening to music.
qa Ear pad
qs DC IN 3 V jack
qd Left (L) unit
qf L (left) indication
qg Headband
GETTING STARTED
* This button has a tactile dot.
