Sony DSC-F717 Service Manual

4-74
DSC-F717
COVER
COVER
3.0 Vp-p
V
H
H
3.0 Vp-p
4
IC102 qh REC
Q301 E REC/PB
5
4.3 Vp-p
22.5 MHz
360 mVp-p
H
Q304 E REC/PB
8
580 mVp-p
IC101 ef REC
2
IC101 eg REC
3
9
IC507 2 (X501) REC/PB
IC507 4 REC/PB
q;
4.8 Vp-p
27 MHz
4.6 Vp-p
45 MHz
IC101 wh REC/PB
1
3.6 Vp-p
45 MHz
H
Q303 E REC/PB
7
500 mVp-p
H
Q302 E REC/PB
6
470 mVp-p
4-4. WAVEFORMS
SY-080 BOARD SIDE A SY-080 BOARD SIDE B
SY-080 BOARD SIDE A SY-080 BOARD SIDE B
SY-080 BOARD
SY-080
