Connections for an A/B Roll Editing System
Chapter 5 Connections and Settings
Settings on an editing control unit
When connecting an editing control unit, make the settings
as follows, according to the model.
PVE-500
No settings are required.
BVE-600/900/910/2000 (NTSC model) or FXE-100/
120
Set the VCR constants as follows.
BVE-600/900/910/2000 (PAL model) or FXE-100P/
120P
Set the VCR constants as follows.
RM-450/RM-450CE
Set the DIP switches as follows.
• Left switches
• Right switches (RM-450)
)
• Right switches (RM-450CE)
BVE-800
Set the DIP switches as follows.
• SW2
• SW3 (NTSC model)
• SW3 (PAL model)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
80 17 00 96 05 05 03 80 0A 08 FE 00 80 5A FF
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
81 17 00 7D 05 05 02 80 0A 07 FE 00 80 4C FF
76543210
OFF −−OFF −−−−
76543210
OFF − OFF ON OFF OFF ON ON
76543210
ON − OFF ON OFF OFF ON ON
12345678
ON OFF ON ON − ON ON −
12345678
ON ON ON OFF − ON OFF OFF
12345678
OFF OFF OFF ON − ON OFF OFF
