Sony DSR-400 User Manual

4-8
DSR-400/V2(J, E)
4-8
2
3
4
5
ABCDEFGH
1
CN2
1H_CLAMP_IN 2V8 3SG4 4V7 5V6 6SG3 7V5 8V2 9SG1
10V1 11V4 12SG2 13V3 14-8V 15-8V 16VSUB 17GND 18TEMP+ 19WBCP(X) 20WBCP(G) 21GND 22GND 23SHUTTER 24+3V 25RG_BIAS 26GND 27GND 28+15V 29+15V 30VL 31SHP 32GND 33SHD 34+6.0 35+6.0 36RG 37GND 38LH1 39GND 40H1 41GND 42H2 43GND 44GND 45DEF(X) 46PA_ID 47LD_PA_IN 48SDA_PA_IN 49SCL_PA_IN 50BSH_IN 51H_CLAMP_IN 52V8 53SG4 54V7 55V6 56SG3 57V5 58V2 59SG1 60V1 61V4 62SG2 63V3 64-8V 65-8V 66VSUB 67GND 68TEMP+ 69WBCP(X) 70WBCP(G) 71GND 72GND 73SHUTTER 74+3V 75RG_BIAS 76GND 77GND 78+15V 79+15V 80VL 81SHP 82GND 83SHD 84+6.0 85+6.0 86RG 87GND 88LH1 89GND 90H1 91GND 92H2 93GND 94GND 95DEF(X) 96PA_ID 97LD_PA_IN 98SDA_PA_IN 99SCL_PA_IN
100BSH_IN
101102
CN1
1+3.3V 2FILTER_POSITION 3FILTER_POSITION 4FILTER_POSITION 5FILTER_POSITION 6GND 7NC 8NC 9NC
10NC 11H_CLAMP_IN 12V8 13SG4 14V7 15V6 16SG3 17V5 18V2 19SG1 20V1 21V4 22SG2 23V3 24-8V 25-8V 26VSUB 27GND 28TEMP+ 29WBCP(X) 30WBCP(G) 31GND 32GND 33SHUTTER 34+3V 35RG_BIAS 36GND 37GND 38+15V 39+15V 40VL 41SHP 42GND 43SHD 44+6.0 45+6.0 46RG 47GND 48LH1 49GND 50H1 51GND 52H2 53GND 54GND 55DEF(X) 56PA_ID 57LD_PA_IN 58SDA_PA_IN 59SCL_PA_IN 60BSH_IN
61 62
CN4
NM
1 H_CLAMP_IN 2V8 3 SG4 4V7 5V6 6 SG3 7V5 8V2 9 SG1
10 V1 11 V4 12 SG2 13 V3 14 -8V 15 -8V 16 VSUB 17 GND 18 TEMP+ 19 WBCP(X) 20 WBCP(G) 21 GND 22 GND 23 SHUTTER 24 +3V 25 RG_BIAS 26 GND 27 GND 28 +15V 29 +15V 30 VL 31 SHP 32 GND 33 SHD 34 +6.0 35 +6.0 36 RG 37 GND 38 LH1 39 GND 40 H1 41 GND 42 H2 43 GND 44 GND 45 DEF(X) 46 PA_ID 47 LD_PA_IN 48 SDA_PA_IN 49 SCL_PA_IN 50 BSH_IN
51525354
CN5
NM
1 H_CLAMP_IN 2V8 3 SG4 4V7 5V6 6 SG3 7V5 8V2 9 SG1
10 V1 11 V4 12 SG2 13 V3 14 -8V 15 -8V 16 VSUB 17 GND 18 TEMP+ 19 WBCP(X) 20 WBCP(G) 21 GND 22 GND 23 SHUTTER 24 +3V 25 RG_BIAS 26 GND 27 GND 28 +15V 29 +15V 30 VL 31 SHP 32 GND 33 SHD 34 +6.0 35 +6.0 36 RG 37 GND 38 LH1 39 GND 40 H1 41 GND 42 H2 43 GND 44 GND 45 DEF(X) 46 PA_ID 47 LD_PA_IN 48 SDA_PA_IN 49 SCL_PA_IN 50 BSH_IN
51525354
CN6
NM
1 H_CLAMP_IN 2V8 3 SG4 4V7 5V6 6 SG3 7V5 8V2 9 SG1
10 V1 11 V4 12 SG2 13 V3 14 -8V 15 -8V 16 VSUB 17 GND 18 TEMP+ 19 WBCP(X) 20 WBCP(G) 21 GND 22 GND 23 SHUTTER 24 +3V 25 RG_BIAS 26 GND 27 GND 28 +15V 29 +15V 30 VL 31 SHP 32 GND 33 SHD 34 +6.0 35 +6.0 36 RG 37 GND 38 LH1 39 GND 40 H1 41 GND 42 H2 43 GND 44 GND 45 DEF(X) 46 PA_ID 47 LD_PA_IN 48 SDA_PA_IN 49 SCL_PA_IN 50 BSH_IN
51525354
CN3
1 +3.3V 2 FILTER_POSITION1 3 FILTER_POSITION2 4 FILTER_POSITION3 5 FILTER_POSITION4 6 GND
78
CN-2437 CN-2437
CCD block flexible board
CN-2437
BOARD NO. 1-860-107-11

Sony DSR-400 Specifications

General

Brand	Sony
Model	DSR-400
Category	Camcorder
Language	English
