15
Basic Functions
The initial values are those set at the factory. Settings
for items in Position presets 1 to 6 that will be retained
even when the power to the camera is turned off are
indicated by a “Yes,” those that will be lost are indicated
by an “No.”
When the power is turned on, the settings retained in
POSITION 1 will be called up as the initial settings.
When a CAM_Memory Reset command is sent, or a
choice is made from POSITION 1 to 6 while the
RESET button on the Remote Commander is being
pressed, the settings selected will be used as the
initial settings.
Position preset 1 becomes VISCA command CAM_
Memory memory number 0. Position presets 2
through 6 become VISCA command CAM_Memory
memory numbers 1 through 5.
Initial Settings and Position Preset
Mode/Position Initial settings
Position
preset 1
Position
presets 2 to 6
Pan/Tilt Position Home position
Pan/Tilt Limit Position movable-range maximum
Zoom Position Wide end
a a
D-Zoom On/Off on
a a
Focus Position —
a a
Focus Auto/Manual Auto
a a
Near Limit Setting 9000h (30 cm)
a a
AF Sensitivity Normal
a a
AF Mode Normal
a a
AF Run Time 5 sec
a a
AF Interval 5 sec
a a
WB Mode Auto
a a
WB Data (Rgain, Bgain) —
a a
One Push WB Data —
a a
AE Mode Full Auto
a a
WD On/Off/Auto Off
a a
Slow Shutter Mode Manual
a a
Shutter Position 1/60sec (NTSC), 1/50sec (PAL)
a a
Iris Position —
a a
Gain Position —
a a
Bright Position —
a a
Exposure Compensation On/Off Off
a a
Exposure Compensation Amount ±0
a a
BackLight On/Off Off
a a
Aperture Level 6
a a
High Resolution Mode On/Off Off
a a
Picture Effect Off
a a
ICR On/Off
1)
Off
a a
Auto ICR On/Off
1)
Off
a a
Auto ICR Threshold Level
1)
0Ah
a a
Image Stabilizer On/Off/Hold
1)
Off
a a
NR Level 3
a a
AE Gain Limit —
a a
Camera ID 0000h
a a
IR_Receive On/Off On
a
IR_ReceiveReturn On/Off Off
a
Display Information On
a
1) The setting is available on EVI-D90N/P only.
Notes
The number of times data can be written to the EEPROM (by executing Position Preset) is limited.
If you want the camera status and Pan/Tilt positions in effect before the camera is turned off to be retained when the power
is turned OFF, then turned ON again, have the camera memorize those positions in POSITION 1.
It takes approximately 2 seconds longer to memorize or erase settings in POSITION 1 than it does to memorize or erase
settings in any other channel.
Camera ID data will be saved regardless of the position preset.
If IMAGE FLIP or D70 mode has been switched, all of the Position Presets are reset to their initial values.
