Command List
FCB-EH6500(GB) A-EEP-100-11(1)
FCB Camera Commands
Command List (1/6)
Command Set Command Command Packet Comments
AddressSet Broadcast 88 30 01 FF Address Setting
IF_Clear – 8x 01 00 01 FF I/F Clear
Broadcast 88 01 00 01 FF
CommandCancel – 8x 2p FF p: Socket No. (=1 or 2)
CAM_Power On 8x 01 04 00 02 FF Power On/Off
Off (Standby) 8x 01 04 00 03 FF
CAM_Zoom Stop 8x 01 04 07 00 FF –
Tele (Standard) 8x 01 04 07 02 FF
Wide (Standard) 8x 01 04 07 03 FF
Tele (Variable) 8x 01 04 07 2p FF p=0 (Low) to 7 (High)
Wide (Variable) 8x 01 04 07 3p FF
Direct 8x 01 04 47 0p 0q 0r 0s FF pqrs: Zoom Position
CAM_DZoom On 8x 01 04 06 02 FF Digital Zoom On/Off
Off 8x 01 04 06 03 FF
Combine Mode 8x 01 04 36 00 FF Optical/Digital Zoom Combined
Separate Mode 8x 01 04 36 01 FF Optical/Digital Zoom Separate
Stop 8x 01 04 06 00 FF –
Tele (Variable) 8x 01 04 06 2p FF p=0 (Low) to 7 (High)
* Enabled during Separate Mode
Wide (Variable) 8x 01 04 06 3p FF
x1/Max 8x 01 04 06 10 FF x1/MAX Magnification Switchover
* Enabled during Separate Mode
Direct 8x 01 04 46 00 00 0p 0q FF pq: D-Zoom Position
* Enabled during Separate Mode
CAM_Focus Stop 8x 01 04 08 00 FF –
Far (Standard) 8x 01 04 08 02 FF
Near (Standard) 8x 01 04 08 03 FF
Far (Variable) 8x 01 04 08 2p FF p=0 (Low) to 7 (High)
Near (Variable) 8x 01 04 08 3p FF
Direct 8x 01 04 48 0p 0q 0r 0s FF pqrs: Focus Position
Auto Focus 8x 01 04 38 02 FF AF On/Off
Manual Focus 8x 01 04 38 03 FF
Auto/Manual 8x 01 04 38 10 FF
One Push Trigger 8x 01 04 18 01 FF One Push AF Trigger
Near Limit 8x 01 04 28 0p 0q 0r 0s FF pqrs: Focus Near Limit Position
CAM_AFSensitivity Normal 8x 01 04 58 02 FF AF Sensitivity High/Low
Low 8x 01 04 58 03 FF
CAM_AFMode Normal AF 8x 01 04 57 00 FF AF Movement Mode
Interval AF 8x 01 04 57 01 FF
Zoom Trigger AF 8x 01 04 57 02 FF
Active/Interval Time 8x 01 04 27 0p 0q 0r 0s FF pq: Movement Time, rs: Interval
CAM_IRCorrection Standard 8x 01 04 11 00 FF Focus IR compensation data switching
IR Light 8x 01 04 11 01 FF
CAM_ZoomFocus Direct 8x 01 04 47 0p 0q 0r 0s
0t 0u 0v 0w FF
pqrs: Zoom Position
tuvw: Focus Position
CAM_Initialize Lens 8x 01 04 19 01 FF Lens Initialization Start
Camera 8x 01 04 19 03 FF Camera reset
