77
US
Quick reference
Built-in microphone
Flash
Lens (G lens)
MIC (PLUG IN POWER) jack
(headphones) jack
Remote sensor/Infrared port
Camera recording lamp (64)
The camera recording lamp lights up in red
during recording. The lamp flashes when the
remaining recording media capacity or battery
power is low.
MANUAL button (29)
MANUAL dial (29)
LCD screen/Touch panel
If you rotate the LCD panel 180 degrees, you
can close the LCD panel with the LCD screen
facing out. This is convenient during playback
operations.
HDR-CX550/CX550V
HDR-XR550/XR550V
(VIEW IMAGES) button (30)
(DISC BURN) button (44)
NIGHTSHOT button (29)
(INTELLIGENT AUTO) button
POWER button (18)
RESET button
Press RESET using a pointed object.
Press RESET to initialize all the settings
including the clock setting.
GPS switch (HDR-CX550V/XR550V) (28)
Speaker
MODE button (24)
(Movie)/ (Photo) lamps (24)
(USB) jack (40, 44, 45, 49, 52)
HDMI OUT jack (33)
