Parts and controls
Figures in ( ) are reference pages.
Speaker (DCR-PJ5E)
Lens
LENS COVER switch
Built-in microphone
LED VIDEO LIGHT (15)
DCR-SR21E/SX21E
LCD screen
LIGHT button (15)
Multi-selector (6)
(VIEW IMAGES) button (16, 22, 26)
DCR-PJ5E
LCD screen
LIGHT button (15)
Multi-selector (6)
(VIEW IMAGES) button (16, 22, 26)
PROJECTOR button (20)
Projector lens
PROJECTOR FOCUS lever
Speaker (DCR-SR21E/SX21E)
(USB) jack (23, 25, 28, 32)
A/V OUT jack (22, 26)
PROJECTOR IN jack (DCR-PJ5E) (21)
MODE button (14)
(INTELLIGENT AUTO) button
RESET button (44)
