Sony HCD-EX6 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EX6/EX6T/EX8/EX8T/EX9/EX9T
5353
BD74
R131 1-216-295-91 SHORT CHIP 0
R201 1-218-446-11 METAL CHIP 1 5% 1/10W
R202 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R203 1-216-864-11 SHORT CHIP 0
R301 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R302 1-216-839-11 METAL CHIP 33K 5% 1/10W
R303 1-216-834-11 METAL CHIP 12K 5% 1/10W
R304 1-216-833-11 METAL CHIP 10K 5% 1/10W
R305 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R401 1-216-295-91 SHORT CHIP 0
R402 1-216-295-91 SHORT CHIP 0
R403 1-216-809-11 METAL CHIP 100 5% 1/10W
R404 1-216-809-11 METAL CHIP 100 5% 1/10W
R405 1-216-809-11 METAL CHIP 100 5% 1/10W
R406 1-216-809-11 METAL CHIP 100 5% 1/10W
R407 1-216-809-11 METAL CHIP 100 5% 1/10W
R408 1-216-809-11 METAL CHIP 100 5% 1/10W
R409 1-216-809-11 METAL CHIP 100 5% 1/10W
R411 1-216-809-11 METAL CHIP 100 5% 1/10W
R412 1-216-809-11 METAL CHIP 100 5% 1/10W
R413 1-216-809-11 METAL CHIP 100 5% 1/10W
R414 1-216-809-11 METAL CHIP 100 5% 1/10W
R415 1-216-809-11 METAL CHIP 100 5% 1/10W
R416 1-216-809-11 METAL CHIP 100 5% 1/10W
R417 1-216-295-91 SHORT CHIP 0
< VIBRATOR >
X101 1-795-101-21 VIBRATOR, CERAMIC (16.934MHz)
*************************************************************
A-1748-774-A DECK BOARD, COMPLETE (EX6T/EX8T/EX9T)
*********************
< CAPACITOR >
C501 1-126-933-11 ELECT 100uF 20% 16V
C502 1-126-933-11 ELECT 100uF 20% 16V
C503 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C504 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C506 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C509 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C510 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C511 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C512 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C513 1-126-960-11 ELECT 1uF 20% 50V
C514 1-126-960-11 ELECT 1uF 20% 50V
C515 1-126-947-11 ELECT 47uF 20% 35V
C516 1-126-947-11 ELECT 47uF 20% 35V
C517 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C519 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C520 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C521 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C522 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C523 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C524 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C525 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C526 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C527 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C528 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C529 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C530 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
DECK
C531 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C532 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C533 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C534 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C535 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C536 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C537 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C538 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C539 1-115-156-11 CERAMIC CHIP 1uF 10V
C540 1-130-479-91 MYLAR 0.0047uF 5% 50V
C542 1-104-662-91 ELECT 22uF 20% 25V
C543 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C545 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C546 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C547 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C548 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C549 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN501 1-815-449-11 PIN, CONNECTOR (PWB) 8P
CN502 1-784-770-11 CONNECTOR, FFC 9P
< IC >
IC501 8-759-278-58 IC NJM4558V-TE2
IC502
8-759-278-58 IC NJM4558V-TE2
< JUMPER RESISTOR >
JR501 1-216-864-11 SHORT CHIP 0
JR502 1-216-864-11 SHORT CHIP 0
JR503 1-216-864-11 SHORT CHIP 0
< TRANSFORMER >
L501 1-456-094-11 TRANSFORMER, BIAS OSCILLATION
< TRANSISTOR >
Q501 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q502 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R501 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R502 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R503 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R504 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R505 1-216-835-11 METAL CHIP 15K 5% 1/10W
R506 1-216-835-11 METAL CHIP 15K 5% 1/10W
R507 1-216-851-11 METAL CHIP 330K 5% 1/10W
R508 1-216-851-11 METAL CHIP 330K 5% 1/10W
R509 1-216-811-11 METAL CHIP 150 5% 1/10W
R510 1-216-811-11 METAL CHIP 150 5% 1/10W
R511 1-216-845-11 METAL CHIP 100K 5% 1/10W
R512 1-216-845-11 METAL CHIP 100K 5% 1/10W
R513 1-216-845-11 METAL CHIP 100K 5% 1/10W
R514 1-216-845-11 METAL CHIP 100K 5% 1/10W
R515 1-216-864-11 SHORT CHIP 0
R516 1-216-864-11 SHORT CHIP 0
R517 1-216-821-11 METAL CHIP 1K 5% 1/10W
R518 1-216-821-11 METAL CHIP 1K 5% 1/10W
R519 1-216-841-11 METAL CHIP 47K 5% 1/10W
R520 1-216-841-11 METAL CHIP 47K 5% 1/10W
