• Waveforms
– MAIN Board – – IO-COMPONENT Board –
 IC4002  (Cin)
500 mV/DIV, 20 μs/DIV
 IC4002  (Yin)
500 mV/DIV, 20 μs/DIV
 IC4002  (CYin)
500 mV//DIV, 20 μs/DIV
 IC4002 RT (Cb in)
200 mV/DIV, 20 μs/DIV
 IC4002 RG (Cr in)
200 mV/DIV, 20 μs/DIV
 IC4002 X (CY OUT)
1 V/DIV, 20 μs/DIV
 IC4002 RL (Cb OUT)
500 mV/DIV, 20 μs/DIV
 IC4002 RI (Cr OUT)
500 mV/DIV, 20 μs/DIV
 IC4002 XE (CVBS OUT)
1 V/DIV, 20 μs/DIV
0.72Vp-p
0.72Vp-p
H
1Vp-p
H
1Vp-p
H
H
1Vp-p
H
2Vp-p
1Vp-p
H
2Vp-p
H
H
H
2.6Vp-p
 IC1101  (DVDRFIP)
200 mV/DIV, 100 ns/DIV
 IC1101 [Y (R/Cr/Pr)
200 mV/DIV, 20 μs/DIV
 IC1101 [D (B/Cb/Pb)
200 mV/DIV, 20 μs/DIV
 IC1101 [C (Y/G)
500 mV/DIV, 20 μs/DIV
 IC1101 [ (C)
500 mV/DIV, 20 μs/DIV
 IC1101 [[ (Y)
500 mV/DIV, 20 μs/DIV
 IC1101 YD (XTALO)
500 mV/DIV, 20 ns/DIV
 IC503 RE (Xout)
1 V/DIV, 100 ns/DIV
 IC304 RE (CKOUT(O))
1 V/DIV, 20 ns/DIV
 IC304 RG (BCK(O))
1 V/DIV, 50 ns/DIV
RB IC304 RH (LRCK(O))
1 V/DIV, 5 μs/DIV
RT IC304 XB (XOUT(O))
1 V/DIV, 20 ns/DIV
RE IC3051  (3Y)
1 V/DIV, 10 ns/DIV
RG IC3010 SL (XFSOIN)
1 V/DIV, 10 ns/DIV
RH IC3010 RG (XFSOOUT)
1 V/DIV, 10 ns/DIV
0.72Vp-p
0.72Vp-p
H
1Vp-p
H
1Vp-p
H
H
1Vp-p
3.5Vp-p
1.6Vp-p 5Vp-p
4.3Vp-p
4Vp-p
3.5Vp-p
27MHz
3.4Vp-p
5MHz
40.7nsec
163nsec
10.4μsec
24.576MHz
49.1MHz
49.1MHz
49.1MHz
650mVp-p
H
3.5Vp-p
4Vp-p
– S-AIR-INC Board –
1 IC802 5 (2Y)
1 V/DIV, 20 ns/DIV
2 IC807 7 (LRCK)
1 V/DIV, 10 Ps/DIV
3 IC807 8 (BCK)
1 V/DIV, 0.1 Ps/DIV
6 IC805 8 (IBICK)
IC806 8 (IBICK)
1 V/DIV, 0.1 Ps/DIV
5 IC805 7 (ILRCK)
IC806 7 (ILRCK)
1 V/DIV, 10 Ps/DIV
4 IC805 3 (PDN)
IC806 3 (PDN)
1 V/DIV, 50 ms/DIV
3.2Vp-p
12.288MHz
3.2Vp-p
20.8Psec
3.2Vp-p
0.326Psec
3.2Vp-p
0.326Psec
3.2Vp-p
20.8Psec
3.2Vp-p
160msec
– DSP Board –
 IC700 [WD (XTAL)
0.5 V/DIV, 20 ns/DIV
1.8Vp-p
25MHz
