Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-FZ900KW/FZ900M
9595
D2101 6-501-749-01 DIODE MAZ8082G0LS0
D2102 6-501-740-01 DIODE MAZ8068G0LS0
D2103 6-501-740-01 DIODE MAZ8068G0LS0
D3551 6-500-848-01 DIODE MC2840-T112-1
D3552 6-501-774-01 DIODE MAZ8150G0LS0
D4111 6-501-696-01 DIODE RSA39LTE25
D4112 6-501-696-01 DIODE RSA39LTE25
D4151 6-501-696-01 DIODE RSA39LTE25
D4152 6-501-696-01 DIODE RSA39LTE25
D4201 6-501-696-01 DIODE RSA39LTE25 (FZ900M)
D4202 6-501-696-01 DIODE RSA39LTE25 (FZ900M)
D4251 6-501-696-01 DIODE RSA39LTE25 (FZ900M)
D4252 6-501-696-01 DIODE RSA39LTE25 (FZ900M)
D4301 6-501-696-01 DIODE RSA39LTE25
D4302 6-501-696-01 DIODE RSA39LTE25
D4401 6-501-696-01 DIODE RSA39LTE25
D4402 6-501-696-01 DIODE RSA39LTE25
D4501 6-501-696-01 DIODE RSA39LTE25
D4502 6-501-696-01 DIODE RSA39LTE25
D9712 6-501-817-01 DIODE MA2J1110GLS0
< FERRITE BEAD >
FB1106 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1107 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1108 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1109 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1111 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1112 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1113 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1115 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1116 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1117 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1118 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB2101 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB2102 1-469-379-11 FERRITE, EMI (SMD) (2012)
FB2103 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB2104 1-469-379-11 FERRITE, EMI (SMD) (2012)
FB2105 1-469-379-11 FERRITE, EMI (SMD) (2012)
FB2120 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2121 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2122 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2124 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2125 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB3107 1-469-118-21 FERRITE, EMI (SMD) (1608) (FZ900KW)
FB3108 1-469-118-21 FERRITE, EMI (SMD) (1608) (FZ900KW)
FB3109 1-469-118-21 FERRITE, EMI (SMD) (1608) (FZ900KW)
< IC >
IC303 6-710-554-01 IC PCM1808PWR
IC304 6-805-692-01
IC LC890561W
* IC306 6-707-847-01 IC TC74LCX157FT(EKJ)
IC451 8-759-710-97 IC NJM4565M-D
IC452 6-712-613-01 IC SI-3010KM-TLS
IC501 6-706-492-01 IC TC7SHU04FU(T5RSOJF)
IC502 6-600-466-01 IC TORX147L(SONY) (TV (DIGITAL IN OPTICAL))
IC503 A-1609-796-A IC R5F3640MDFAR (for SERVICE)
IC504 6-705-338-01 IC TK11250CMCL-G
IC505 6-713-500-01 IC BR24S16F-WE2
IC506 6-705-203-01 IC S-80935CNMC-G85T2G
IC507 6-712-613-01 IC SI-3010KM-TLS
IC508 6-705-337-01 IC TK11150CSCL-G
IC509 6-712-613-01 IC SI-3010KM-TLS
IC510 6-712-613-01 IC SI-3010KM-TLS
IC1101 6-713-716-01 IC CXD9917R-A
IC1102 6-808-755-01 IC MX29LV320DBTI-70-OHE-0903UC (E32)
IC1102 6-808-756-01 IC MX29LV320DBTI-70-OHE-0903CE
(E3,E12,E15,AUS,EA,RU)
IC1102 6-808-757-01 IC MX29LV320DBTI-70-OHE-0903GA (SP,TH)
IC1103 (Not supplied) IC BR24S64F-WE2
IC1104 6-713-754-01 IC W9864G6IH-6J-ER10
IC1105 6-702-302-01 IC TK11133CSCL-G
IC1107 6-702-302-01 IC TK11133CSCL-G
IC1110 6-707-739-01 IC MM1661JTRE
IC1201 6-704-524-01 IC FAN8036L
IC1705 8-759-592-47 IC TC7SZ08FU(TE85R)
IC1707 6-705-337-01 IC TK11150CSCL-G
IC1708 6-702-302-01 IC TK11133CSCL-G
IC2101 8-759-700-07 IC NJM2903M
IC3001 8-759-710-97 IC NJM4565M-D (FZ900KW)
IC3010 6-705-979-01 IC CXD9788AR
IC3020 6-705-979-01 IC CXD9788AR (FZ900M)
IC3030 6-705-979-01 IC CXD9788AR
IC3050 6-702-300-01 IC TK11118CSCL-G
IC3051 6-709-888-01 IC TC7WHU04FK(T5RSOYF
IC3100 6-712-370-01 IC CXD9936TN
IC3150 6-712-370-01 IC CXD9936TN
IC3200 6-712-370-01 IC CXD9936TN (FZ900M)
IC3250 6-712-370-01 IC CXD9936TN (FZ900M)
IC3300 6-712-370-01 IC CXD9936TN
IC3400 6-712-370-01 IC CXD9936TN
IC3500 6-712-370-01 IC CXD9936TN
< JACK >
J501 1-822-282-1
1 JACK, PIN 1P (TV (DIGITAL IN COAXIAL))
< COIL >
L301 1-469-525-91 INDUCTOR 10uH
L302 1-469-525-91 INDUCTOR 10uH
L303 1-469-525-91 INDUCTOR 10uH
L451 1-469-525-91 INDUCTOR 10uH
L501 1-469-525-91 INDUCTOR 10uH
L502 1-469-525-91 INDUCTOR 10uH
L1701 1-457-374-21 COIL, COMMON MODE CHOKE
L1702 1-457-374-21 COIL, COMMON MODE CHOKE
L1703 1-457-374-21 COIL, COMMON MODE CHOKE
L1704 1-457-374-21 COIL, COMMON MODE CHOKE
L2101 1-457-374-21 COIL, COMMON MODE CHOKE
L3000 1-469-527-91 INDUCTOR 47uH
L3051 1-469-525-91 INDUCTOR 10uH
L3052 1-469-525-91 INDUCTOR 10uH
L3053 1-469-525-91 INDUCTOR 10uH
L3054 1-412-939-11 INDUCTOR 1uH
L3101 1-457-579-11 COIL, CHOKE 10uH
L3102 1-457-579-11 COIL, CHOKE 10uH
L3201 1-457-579-11 COIL, CHOKE 10uH (FZ900M)
L3202 1-457-579-11 COIL, CHOKE 10uH (FZ900M)
L3301 1-457-579-11 COIL, CHOKE 10uH
L3401 1-457-579-11 COIL, CHOKE 10uH
L3501 1-457-579-11 COIL, CHOKE 10uH
L3901 1-457-078-11 COIL, AIR-CORE
L3902 1-457-077-11 COIL, AIR-CORE
MAIN
When IC1103 on the Main board is damaged, exchange
the new Main board for the Main board which IC damaged.
