HCD-MX700Ni/MX750Ni
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
7777
FB1008 1-216-864-11 SHORT CHIP 0
FB1009 1-216-864-11 SHORT CHIP 0
FB1011 1-216-864-11 SHORT CHIP 0
FB1012 1-216-864-11 SHORT CHIP 0
FB1013 1-216-864-11 SHORT CHIP 0
FB1014 1-216-864-11 SHORT CHIP 0
FB1015 1-216-864-11 SHORT CHIP 0
FB1016 1-216-864-11 SHORT CHIP 0
FB1017 1-216-864-11 SHORT CHIP 0
FB1019 1-216-864-11 SHORT CHIP 0
FB1020 1-216-864-11 SHORT CHIP 0
FB1021 1-216-864-11 SHORT CHIP 0
FB1022 1-216-864-11 SHORT CHIP 0
FB1023 1-216-864-11 SHORT CHIP 0
FB1024 1-216-864-11 SHORT CHIP 0
FB1025 1-218-990-11 SHORT CHIP 0
< IC >
IC1001 6-713-862-01 IC AK4388AET-E2
IC1002 6-714-032-01 IC BD9321EFJ-E2
IC1003 6-712-613-01 IC SI-3010KM-TLS
IC1004
6-715-134-01 IC MM3404A33URE
IC1005 6-715-392-01 IC AK5358BET-E2
< COIL >
L1001 1-424-918-21 INDUCTOR 10uH
< RESISTOR >
R1008 1-218-941-11 METAL CHIP 100 5% 1/16W
R1009 1-216-295-00 SHORT CHIP 0
R1010 1-216-295-00 SHORT CHIP 0
R1011 1-218-990-11 SHORT CHIP 0
R1012 1-218-990-11 SHORT CHIP 0
R1013 1-216-295-00 SHORT CHIP 0
R1014 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1015 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1016 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1017 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1018 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1019 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1020 1-218-990-11 SHORT CHIP 0
R1021 1-218-990-11 SHORT CHIP 0
R1022 1-218-937-11 METAL CHIP 47 5% 1/16W
R1023 1-218-990-11 SHORT CHIP 0
R1024 1-218-937-11 METAL CHIP 47 5% 1/16W
R1025 1-218-990-11 SHORT CHIP 0
R1026 1-218-937-11 METAL CHIP 47 5% 1/16W
R1027 1-218-937-11 METAL CHIP 47 5% 1/16W
R1028 1-218-990-11 SHORT CHIP 0
R1030 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1031 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1034 1-218-937-11 METAL CHIP 47 5% 1/16W
R1035 1-218-937-11 METAL CHIP 47 5% 1/16W
R1036 1-218-937-11 METAL CHIP 47 5% 1/16W
R1037 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1038 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1039 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1040 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1041 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1042 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1043 1-218-937-11 METAL CHIP 47 5% 1/16W
R1044 1-218-937-11 METAL CHIP 47 5% 1/16W
R1045 1-218-937-11 METAL CHIP 47 5% 1/16W
R1046 1-218-937-11 METAL CHIP 47 5% 1/16W
R1047 1-218-941-11 METAL CHIP 100 5% 1/16W
R1049 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R1050 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R1051 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R1052 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R1053 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R1054 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R1055 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1056 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1057 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1058 1-216-817-11 METAL CHIP 470 5% 1/10W
R1059 1-216-817-11 METAL CHIP 470 5% 1/10W
R1060 1-218-990-11 SHORT CHIP 0
R1061 1-218-990-11 SHORT CHIP 0
R1062 1-218-990-11 SHORT CHIP 0
R1063 1-218-990-11 SHORT CHIP 0
R1064 1-218-285-11 METAL CHIP 75 5% 1/10W
R1065 1-218-285-11 METAL CHIP 75 5% 1/10W
R1067 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R1068 1-218-937-11 METAL CHIP 47 5% 1/16W
R1069 1-218-937-11 METAL CHIP 47 5% 1/16W
R1070 1-218-937-11 METAL CHIP 47 5% 1/16W
R1071 1-218-937-11 METAL CHIP 47 5% 1/16W
R1072 1-218-990-11 SHORT CHIP 0
R1073 1-218-990-11 SHORT CHIP 0
R1074 1-218-990-11 SHORT CHIP 0
R1075 1-218-990-11 SHORT CHIP 0
R1076 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1077 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1078 1-216-817-11 METAL CHIP 470 5% 1/10W
R1079 1-216-817-11 METAL CHIP 470 5% 1/10W
R1080 1-216-864-11 SHORT CHIP 0
R1081 1-218-941-11 METAL CHIP 100 5% 1/16W
R1082 1-216-809-11 METAL CHIP 100 5% 1/10W
R1083 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1084 1-216-864-11 SHORT CHIP 0
R1085 1-216-864-11 SHORT CHIP 0
R1086 1-216-864-11 SHORT CHIP 0
R1087 1-216-864-11 SHORT CHIP 0
R1088 1-216-864-11 SHORT CHIP 0
R1089 1-216-864-11 SHORT CHIP 0
R1090 1-216-864-11 SHORT CHIP 0
R1091 1-216-864-11 SHORT CHIP 0
R1092 1-216-158-00 METAL CHIP 22 5% 1/8W
*************************************************************
POWER BOARD
*************
< CAPACITOR >
0 C1 1-165-529-11 MYLAR 0.22uF 10% 250V
0 C2 1-165-529-11 MYLAR 0.22uF 10% 250V
0 C4 1-119-886-51 CERAMIC 470PF 10% 250V
0 C5 1-119-886-51 CERAMIC 470PF 10% 250V
0 C10 1-100-923-21 ELECT 100uF 20% 450V
(AEP, UK)
