HCD-MX700Ni/MX750Ni
8
POWER BOARD SERVICE POSITION
Note: Please disassemble each board from the chassis.
MAIN board
POWER board
LCD board
MAIN BOARD (CONDUCTOR SIDE) AND BD96U BOARD (CONDUCTOR SIDE) SERVICE POSITION
BD96U board
(conductor side)
MAIN board
(conductor side)
POWER board
DAB board
(MX750Ni only)
