5-20
Ref. No. Part No. Description Ref. No. Part No. Description
HXR-MC1/MC1P
L1502 1-400-588-11 INDUCTOR 10uH
L2401 1-400-342-21 INDUCTOR 10uH
L2403 1-400-342-21 INDUCTOR 10uH
L2501 1-400-342-21 INDUCTOR 10uH
L2502 1-400-675-11 INDUCTOR 10uH
L2503 1-400-342-21 INDUCTOR 10uH
* L2504 1-400-672-11 INDUCTOR 1uH
< TRANSISTOR >
* Q1701 6-551-771-01 TRANSISTOR UNR31AFG0LS0
* Q2403 6-551-157-01 TRANSISTOR 2SA207900AS0
* Q2404 6-551-157-01 TRANSISTOR 2SA207900AS0
* Q2405 6-551-157-01 TRANSISTOR 2SA207900AS0
* Q2406 6-551-157-01 TRANSISTOR 2SA207900AS0
* Q2407 6-551-157-01 TRANSISTOR 2SA207900AS0
* Q2408 6-551-157-01 TRANSISTOR 2SA207900AS0
< RESISTOR >
R1008 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1009 1-240-708-91 METAL CHIP 12K 5% 1/20W
R1019 1-694-535-91 SHORT CHIP 0
R1030 1-240-716-91 METAL CHIP 68K 5% 1/20W
R1031 1-240-700-91 METAL CHIP 2.7K 5% 1/20W
R1301 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1302 1-694-535-91 SHORT CHIP 0
R1304 1-240-676-91 METAL CHIP 22 5% 1/20W
R1306 1-218-933-11 METAL CHIP 22 5% 1/16W
R1307 1-216-809-11 METAL CHIP 100 5% 1/10W
R1308 1-216-809-11 METAL CHIP 100 5% 1/10W
R1312 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1314 1-240-714-91 METAL CHIP 47K 5% 1/20W
R1315 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1317 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1318 1-694-535-91 SHORT CHIP 0
R1319 1-694-535-91 SHORT CHIP 0
R1320 1-218-935-11 METAL CHIP 33 5% 1/16W
R1328 1-694-535-91 SHORT CHIP 0 (MC1)
R1333 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1334 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1336 1-240-718-91 METAL CHIP 100K 5% 1/20W
(MC1P)
R1344 1-694-535-91 SHORT CHIP 0
R1345 1-694-535-91 SHORT CHIP 0
R1356 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1357 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1358 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1359 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1368 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1370 1-694-535-91 SHORT CHIP 0
R1372 1-218-990-81 SHORT CHIP 0
R1373 1-694-535-91 SHORT CHIP 0
R1376 1-218-990-81 SHORT CHIP 0
R1384 1-481-067-21 BEAD, FERRITE (1005) (Note)
R1387 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1502 1-216-864-11 SHORT CHIP 0
R1503 1-216-864-11 SHORT CHIP 0
R1504 1-216-864-11 SHORT CHIP 0
R1505 1-216-864-11 SHORT CHIP 0
R1507 1-216-864-11 SHORT CHIP 0
R1508 1-216-295-91 SHORT CHIP 0
R1602 1-216-864-11 SHORT CHIP 0
R1701 1-218-990-81 SHORT CHIP 0
R1704 1-694-535-91 SHORT CHIP 0 (MC1P)
R1705 1-694-535-91 SHORT CHIP 0 (MC1)
R1706 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1707 1-216-295-91 SHORT CHIP 0
* R1708 1-240-779-91 METAL CHIP 620 0.5% 1/20W
R1709 1-240-808-11 METAL CHIP 10K 0.5% 1/20W
R1711 1-240-760-91 METAL CHIP 100 0.5% 1/20W
R1712 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R1713 1-240-784-91 METAL CHIP 1K 0.5% 1/20W
R1715 1-218-990-81 SHORT CHIP 0
R1716 1-240-679-91 METAL CHIP 47 5% 1/20W
R1717 1-240-678-91 METAL CHIP 33 5% 1/20W
R1718 1-240-679-91 METAL CHIP 47 5% 1/20W
R1719 1-694-535-91 SHORT CHIP 0
R1720 1-240-676-91 METAL CHIP 22 5% 1/20W
R1727 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1728 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1729 1-240-676-91 METAL CHIP 22 5% 1/20W
R1730 1-240-676-91 METAL CHIP 22 5% 1/20W
R1739 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1740 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1741 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1742 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1743 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1744 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1745 1-218-989-11 METAL CHIP 1M 5% 1/16W
R1746 1-218-989-11 METAL CHIP 1M 5% 1/16W
R1747 1-240-729-91 METAL CHIP 1M 5% 1/20W
R1748 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1749 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1752 1-240-707-91 METAL CHIP 10K 5% 1/20W
R1753 1-240-707-91 METAL CHIP 10K 5% 1/20W
R1756 1-694-535-91 SHORT CHIP 0
R1759 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1760 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1761 1-218-990-81 SHORT CHIP 0
R1762 1-218-990-81 SHORT CHIP 0
R1815 1-240-684-91 METAL CHIP 120 5% 1/20W
R1820 1-240-684-91 METAL CHIP 120 5% 1/20W
R1828 1-218-990-81 SHORT CHIP 0
R1829 1-218-990-81 SHORT CHIP 0
R1830 1-218-990-81 SHORT CHIP 0
R1831 1-218-990-81 SHORT CHIP 0
R1835 1-240-672-11 METAL CHIP 10 5% 1/20W
R1844 1-694-535-91 SHORT CHIP 0
R1845 1-694-535-91 SHORT CHIP 0
R1847 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1854 1-694-535-91 SHORT CHIP 0
R1855 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1857 1-240-695-91 METAL CHIP 1K 5% 1/20W
R2010 1-218-990-81 SHORT CHIP 0
R2011 1-218-990-81 SHORT CHIP 0
VC-546
Note: Ferrite bead is mounted to the location where R1384 is
printed.
Note: R1384にはフェライトビーズがマウントされています。
Ver. 1.1 2009.01
The changed portions from
Ver. 1.1 are shown in blue.
