Sony HXR-MC1 Operating Guide Service Manual

5-12
Ref. No. Part No. Description Ref. No. Part No. Description
HXR-MC1/MC1P
* VDR705 1-802-251-21 CHIP VARISTOR
* VDR706 1-802-251-21 CHIP VARISTOR
A-1665-271-A LC-096 BOARD, COMPLETE
**********************
< CAPACITOR >
C5404 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5405 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5406 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5407 1-137-987-81 CERAMIC CHIP 0.068uF 10% 10V
C5408 1-137-987-81 CERAMIC CHIP 0.068uF 10% 10V
C5409 1-137-987-81 CERAMIC CHIP 0.068uF 10% 10V
C5411 1-112-534-11 CERAMIC CHIP 10uF 20% 6.3V
C5413 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C5414 1-112-534-11 CERAMIC CHIP 10uF 20% 6.3V
C5415 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C5416 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C5417 1-112-534-11 CERAMIC CHIP 10uF 20% 6.3V
C5418 1-112-534-11 CERAMIC CHIP 10uF 20% 6.3V
C5421 1-112-534-11 CERAMIC CHIP 10uF 20% 6.3V
C5424 1-112-534-11 CERAMIC CHIP 10uF 20% 6.3V
C5425 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5426 1-112-534-11 CERAMIC CHIP 10uF 20% 6.3V
* C5427 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C5428 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5429 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5430 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5431 1-112-534-11 CERAMIC CHIP 10uF 20% 6.3V
C5432 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
* CN5401 1-821-196-11 CONNECTOR, FPC (ZIF) 39P
* CN5402 1-819-450-21 PIN, CONNECTOR (PRINT PWB) 10P
CN5403 1-794-997-11 PIN, CONNECTOR 20P
* CN5404 1-819-451-21 PIN, CONNECTOR (PRINT PWB) 6P
< DIODE >
D5401 6-501-568-01 DIODE RB521CS-30T2R
D5402 6-501-568-01 DIODE RB521CS-30T2R
D5403 6-501-568-01 DIODE RB521CS-30T2R
D5405 6-501-568-01 DIODE RB521CS-30T2R
D5406 6-501-568-01 DIODE RB521CS-30T2R
D5407 6-501-568-01 DIODE RB521CS-30T2R
D5408 6-501-568-01 DIODE RB521CS-30T2R
D5410 6-501-568-01 DIODE RB521CS-30T2R
< IC >
IC5401 6-707-702-01 IC NJM2746RB1 (TE2)
IC5402 6-707-702-01 IC NJM2746RB1 (TE2)
IC5403 6-705-881-01 IC HD74ALVC1G125VSE-E
< COIL >
L5401 1-400-353-21 INDUCTOR 22uH
< TRANSISTOR >
Q5401 8-729-427-72 TRANSISTOR XP4501
< RESISTOR >
R5402 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R5403 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R5404 1-219-600-11 METAL CHIP 56K 0.5% 1/16W
R5405 1-219-600-11 METAL CHIP 56K 0.5% 1/16W
R5406 1-219-600-11 METAL CHIP 56K 0.5% 1/16W
R5407 1-219-600-11 METAL CHIP 56K 0.5% 1/16W
R5408 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R5409 1-219-600-11 METAL CHIP 56K 0.5% 1/16W
R5410 1-219-600-11 METAL CHIP 56K 0.5% 1/16W
R5411 1-219-600-11 METAL CHIP 56K 0.5% 1/16W
R5412 1-219-600-11 METAL CHIP 56K 0.5% 1/16W
R5413 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R5414 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R5415 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R5416 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R5417 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R5418 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R5419 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5420 1-218-967-11 METAL CHIP 15K 5% 1/16W
R5427 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5428 1-218-990-81 SHORT CHIP 0
R5430 1-218-990-81 SHORT CHIP 0
R5432 1-218-953-11 METAL CHIP 1K 5% 1/16W
R5433 1-218-953-11 METAL CHIP 1K 5% 1/16W
R5437 1-218-943-11 METAL CHIP 150 5% 1/16W
R5439 1-218-990-81 SHORT CHIP 0
< VIBRATOR >
* X5401 1-813-856-11 OSCILLATOR, CRYSTAL (27MHz)
A-1528-468-A LD-235 BOARD, COMPLETE (MC1)
A-1543-261-A LD-235 BOARD, COMPLETE (MC1P)
**********************
< CAPACITOR >
C5201 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(MC1P)
C5202 1-164-942-11 CERAMIC CHIP 0.0068uF 10% 16V
(MC1P)
* C5207 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5208 1-100-962-91 TANTAL. CHIP 22uF 20% 6.3V
C5209 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C5210 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5211 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C5212 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C5213 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5214 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5215 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5216 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5217 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5219 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5221 1-100-902-91 TANTAL. CHIP 10uF 20% 10V
C5222 1-100-902-91 TANTAL. CHIP 10uF 20% 10V
C5223 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5224 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
JK-378 LC-096 LD-235
