Sony ILCE-6000 User Manual

GB
10
When the lens is removed
A Shutter button
B C1 (Custom 1) button
C Remote sensor
D ON/OFF (Power) switch
E Self-timer lamp/AF illuminator
F Lens release button
G Microphone
1)
H Lens
I Mount
J Image sensor
2)
K Lens contacts
2)
1)
Do not cover this part during movie
recording.
2)
Do not touch this part directly.
Identifying parts

Sony ILCE-6000 Specifications

General

Sensor Type	APS-C CMOS
Effective Megapixels	24.3 MP
Autofocus Points	179
Continuous Shooting Speed	11 fps
Viewfinder Type	Electronic (OLED)
Screen Size	3.0 inches
Screen Resolution	921, 600 dots
Screen Type	Tilting LCD
File Formats	JPEG, RAW
Connectivity	Wi-Fi, NFC
Battery Type	NP-FW50
Dimensions	120 x 66.9 x 45.1 mm
Lens Mount	Sony E-mount
Viewfinder Coverage	100%
ISO Sensitivity	100-25600
Video Resolution	1920 x 1080
Video Frame Rate	60p/24p
Shutter Speed	1/4000 to 30 sec
Battery Life	360 shots
