Sony KDL-26T3000 User Manual

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 87 -
U2
< COIL >
L250 1-457-223-11 INDUCTOR 0UH
L251 1-457-223-11 INDUCTOR 0UH
L252 1-457-223-11 INDUCTOR 0UH
L253 1-457-223-11 INDUCTOR 0UH
L254 1-457-223-11 INDUCTOR 0UH
L255 1-457-223-11 INDUCTOR 0UH
L256 1-457-223-11 INDUCTOR 0UH
L257 1-457-223-11 INDUCTOR 0UH
< TRANSISTOR >
Q251 8-729-028-28 TRANSISTOR 2SK2036(TE85L)
Q255 8-729-028-96 TRANSISTOR DTC114EUA-T106
< RESISTOR >
R200 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R201 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R202 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R203 1-218-941-81 RES-CHIP 100 5% 1/16W
R204 1-218-285-11 METAL CHIP 75 5% 1/10W
R205 1-218-941-81 RES-CHIP 100 5% 1/16W
R206 1-218-953-11 RES-CHIP 1K 5% 1/16W
R207 1-218-953-11 RES-CHIP 1K 5% 1/16W
R212 1-218-989-11 RES-CHIP 1M 5% 1/16W
R213 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R215 1-218-989-11 RES-CHIP 1M 5% 1/16W
R216 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R218 1-218-990-81 SHORT CHIP 0
R219 1-218-990-81 SHORT CHIP 0
R220 1-218-990-81 SHORT CHIP 0
R221 1-218-990-81 SHORT CHIP 0
R222 1-218-990-81 SHORT CHIP 0
R256 1-218-929-11 RES-CHIP 10 5% 1/16W
R257 1-218-973-11 RES-CHIP 47K 5% 1/16W
R258 1-218-941-81 RES-CHIP 100 5% 1/16W
R259 1-218-941-81 RES-CHIP 100 5% 1/16W
R260 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R261 1-218-973-11 RES-CHIP 47K 5% 1/16W
R262 1-218-973-11 RES-CHIP 47K 5% 1/16W
R263 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R264 1-218-929-11 RES-CHIP 10 5% 1/16W
R265 1-218-929-11 RES-CHIP 10 5% 1/16W
R266 1-218-929-11 RES-CHIP 10 5% 1/16W
R267 1-218-929-11 RES-CHIP 10 5% 1/16W
R269 1-218-929-11 RES-CHIP 10 5% 1/16W
R270 1-218-929-11 RES-CHIP 10 5% 1/16W
R271 1-218-929-11 RES-CHIP 10 5% 1/16W
R272 1-218-929-11 RES-CHIP 10 5% 1/16W
R273 1-218-941-81 RES-CHIP 100 5% 1/16W
* A-1504-449-A U2 COMPLETE (32/40 Inches Only)
< CAPACITOR >
C200 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C201 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C202 1-112-781-11 CERAMIC CHIP 1UF 10% 10V
C204 1-100-905-11 CERAMIC CHIP 0.001UF 10% 50V
C206 1-100-912-11 CERAMIC CHIP 1UF 10% 25V
C207 1-100-905-11 CERAMIC CHIP 0.001UF 10% 50V
C209 1-100-912-11 CERAMIC CHIP 1UF 10% 25V
C211 1-100-905-11 CERAMIC CHIP 0.001UF 10% 50V
C213 1-100-905-11 CERAMIC CHIP 0.001UF 10% 50V
C215 1-100-905-11 CERAMIC CHIP 0.001UF 10% 50V
C216 1-100-905-11 CERAMIC CHIP 0.001UF 10% 50V
C250 1-100-916-11 CERAMIC CHIP 0.1UF 10% 16V
C251 1-112-777-11 CERAMIC CHIP 0.01UF 10% 25V
C252 1-112-777-11 CERAMIC CHIP 0.01UF 10% 25V
C253 1-112-777-11 CERAMIC CHIP 0.01UF 10% 25V
C254 1-100-905-11 CERAMIC CHIP 0.001UF 10% 50V
C258 1-100-905-11 CERAMIC CHIP 0.001UF 10% 50V
C261 1-100-905-11 CERAMIC CHIP 0.001UF 10% 50V
C262 1-112-777-11 CERAMIC CHIP 0.01UF 10% 25V
C263 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C265 1-100-905-11 CERAMIC CHIP 0.001UF 10% 50V
C266 1-100-916-11 CERAMIC CHIP 0.1UF 10% 16V
C267 1-100-916-11 CERAMIC CHIP 0.1UF 10% 16V
< CONNECTOR >
CN201 *1-819-928-11 HEADER ASSENBLY 20P
CN250 *1-818-400-11 HDMI CONNECTOR
CN251 *1-820-667-11 HEADER ASSEMBLY FOR PWB 21P
< DIODE >
D201 8-719-423-03 DIODE MA8100
D202 8-719-423-03 DIODE MA8100
D203 8-719-423-03 DIODE MA8100
D254 8-719-404-50 DIODE MA111-TX
D261 8-719-404-50 DIODE MA111-TX
ET201 1-780-482-11 EARTH TERMINAL
ET203 1-780-482-11 EARTH TERMINAL
< IC >
IC250 6-704-001-01 IC BR24L02F-WE2
IC251 6-708-758-01 IC PCA9517DP.118
IC252 8-753-255-97 IC CXB1441R-T4
< SOCKET >
J201 1-780-489-11 S TERMINAL BLOCK (RIGHT ANGLE)
J202 1-815-325-11 JACK

Sony KDL-26T3000 Specifications

General

Brand	Sony
Model	KDL-26T3000
Category	Flat Panel TV
Language	English
