REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 94 -
BCD1
Note : The components identified by mark
contain confidential information.
Strictly follow the instructions when
ever the components are repaired
and/or replaced.
C1013 1-165-667-21 ELECT CHIP 100UF 20% 6.3V
C1015 1-164-936-11 CERAMIC CHIP 680PF 10.00% 50V
C1016 1-100-907-11 CERAMIC CHIP 0.1UF 10% 10V
C1017 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C1018 1-164-947-11 CERAMIC CHIP 0.01UF 50V
C1019 1-117-681-11 ELECT CHIP 100UF 20.00% 16V
C1020 1-165-667-21 ELECT CHIP 100UF 20% 6.3V
C1021 1-165-667-21 ELECT CHIP 100UF 20% 6.3V
C1022 1-164-936-11 CERAMIC CHIP 680PF 10.00% 50V
C1023 1-164-936-11 CERAMIC CHIP 680PF 10.00% 50V
C1024 1-100-907-11 CERAMIC CHIP 0.1UF 10% 10V
C1026 1-100-907-11 CERAMIC CHIP 0.1UF 10% 10V
C1027 1-100-611-91 CERAMIC CHIP 22UF 20% 6.3V
C1028 1-100-611-91 CERAMIC CHIP 22UF 20% 6.3V
C1029 1-162-961-11 CERAMIC CHIP 330PF 10.00% 50V
C1030 1-164-936-11 CERAMIC CHIP 680PF 10.00% 50V
C1031 1-100-907-11 CERAMIC CHIP 0.1UF 10% 10V
C1032 1-100-907-11 CERAMIC CHIP 0.1UF 10% 10V
C1033 1-124-778-00 ELECT CHIP 22UF 20.00% 6.3V
C1034 1-162-995-11 CERAMIC CHIP 0.022UF 50V
C1035 1-162-995-11 CERAMIC CHIP 0.022UF 50V
C1036 1-128-996-11 ELECT CHIP 4.7UF 20% 50V
C1037 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C1039 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1042 1-100-911-11 CERAMIC CHIP 4.7UF 10% 25V
C1043 1-100-911-11 CERAMIC CHIP 4.7UF 10% 25V
C1044 1-165-667-21 ELECT CHIP 100UF 20% 6.3V
C1045 1-165-667-21 ELECT CHIP 100UF 20% 6.3V
C2004 1-164-227-11 CERAMIC CHIP 0.022UF 10.00% 25V
C2005 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C2006 1-164-227-11 CERAMIC CHIP 0.022UF 10.00% 25V
C2007 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C2014 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C2015 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C2016 1-126-396-11 ELECT CHIP 47UF 20.00% 16V
C2017 1-126-396-11 ELECT CHIP 47UF 20.00% 16V
C2020 1-117-370-11 CERAMIC CHIP 10UF 10V
C2021 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C2022 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C2023 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C2024 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C2025 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C2026 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C2027 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C2028 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C2029 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C2034 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C2035 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C2036 1-164-227-11 CERAMIC CHIP 0.022UF 10.00% 25V
C2037 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
R6773 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6775 1-216-845-11 METAL CHIP 100K 5% 1/10W
R6776 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R6778 1-216-864-11 SHORT CHIP 0
R6779 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R6780 1-216-864-11 SHORT CHIP 0
R6782 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R6783 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R6786 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R6787 1-216-817-11 METAL CHIP 470 5% 1/10W
R6788 1-216-864-11 SHORT CHIP 0
R6789 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R6790 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R6792 1-218-885-11 METAL CHIP 39K 0.5% 1/10W
R6793 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6794 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R6795 1-216-841-11 METAL CHIP 47K 5% 1/10W
R6802 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R6804 1-249-381-11 CARBON 1 5% 1/4W
R6805 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R6806 1-216-864-11 SHORT CHIP 0
R6807 1-216-864-11 SHORT CHIP 0
R6809 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R6810 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R6811 1-218-901-11 METAL CHIP 180K 0.5% 1/10W
R6816 1-216-864-11 SHORT CHIP 0
R6819 1-216-864-11 SHORT CHIP 0
R6823 1-216-864-11 SHORT CHIP 0
R6824 1-216-864-11 SHORT CHIP 0
R6909 1-216-821-11 METAL CHIP 1K 5% 1/10W
< TRANSFORMER >
T6800 1-445-237-11 TRANSFORMER, DRIVE
T6801 8-597-054-00 TRANSFORMER, HIGH-VOLTAGE INSU
* A-1503-609-A BC COMPLETE (26 Inches Only)
* A-1503-611-A BC COMPLETE (32/40 Inches Only)
BC Board Common Parts
< CAPACITOR >
C1000 1-126-204-11 ELECT CHIP 47UF 20.00% 16V
C1001 1-100-907-11 CERAMIC CHIP 0.1UF 10% 10V
C1002 1-100-907-11 CERAMIC CHIP 0.1UF 10% 10V
C1003 1-115-566-11 CERAMIC CHIP 4.7UF 10.00% 10V
C1004 1-164-852-11 CERAMIC CHIP 12PF 5.00% 50V
C1005 1-164-852-11 CERAMIC CHIP 12PF 5.00% 50V
C1006 1-100-907-11 CERAMIC CHIP 0.1UF 10% 10V
C1007 1-164-852-11 CERAMIC CHIP 12PF 5.00% 50V
C1008 1-164-852-11 CERAMIC CHIP 12PF 5.00% 50V
C1010 1-164-852-11 CERAMIC CHIP 12PF 5.00% 50V
