3840×2160: Set to 3840×2160.
4096×2160: Set to 4096×2160.
Settings Relating to
Signal Outputs
Configures settings for outputs and format converter
outputs.
The following output connector boards can be installed in
the XVS-9000/8000/7000/6000.
• XVS-9000
• XVS-8000/7000/6000
a) Interface configured in the Engineering Setup >System >Network Config
>Net I/F Protocol menu (7311.3)
The maximum number of outputs on the XVS-9000 is 80
(40 for 4K format), or 96 (48 for 4K format) when the
multi viewer output connectors are included.
For the XVS-8000/7000/6000, the maximum number of
outputs on the XVS-8000/7000 is 48 (12 for 4K format),
and on the XVS-6000 is 24 (6 for 4K format). The
maximum number of format converter outputs is 16 (4 for
4K format).
59.94 (2×) format output signals are supported on the
XKS-S8165 SDI Output Connector Board only.
Network connector board restrictions
Only the following interface and signal format outputs are
supported, depending on the board.
Output connector board Interface
XKS-S9167 12G-SDI Output Board SDI
XKS-C9121 100G IP Input and Output
Board
ST2110
XKS-C9121N NMI Input and Output Board NMI
Output connector board Interface
XKS-S8165 SDI Output Connector Board SDI
XKS-S8167 12G-SDI Output Board SDI
XKS-T8165 IP Output Connector Board NMI
XKS-Q8166 QSFP IP Output Connector
Board
NMI/ST2110
a)
XKS-C8166 100G IP Output Board ST2110
Note
Board Interface Signal formats
XKS-T8165 NMI • 3840×2160P 2SI (Level A)
a)
• 1080P (Level A)
b)
• 1080i
XKS-Q8166 NMI • 3840×2160P 2SI (Level A)
a)
• 1080P (Level A)
b)
• 1080i
ST2110 • 1080i
c)
